Perfect new design fiber laser marking machine 20w

Product details
Laser Power:20W;Selling Units:Single item;
Applicable Material:Metal/ABS/PC;Applicable Industries:Manufacturing Plant,Retail,Advertising Company;
Brand:MRJ-laser;Working Accuracy:±0.005mm;
Product name:Perfect new design fiber laser marking machine 20w;After-sales Service Provided:Online support,Field installation, commissioning and training,Video technical support;
Keywords:Fiber laser marking machine;Single gross weight:80 KG;
Laser Type:Fiber Laser;Galvanometer:Sino-Galvo;
Control System Brand:Ezcad;Place of Origin:Sichuan China;
Package Type:Durable wooden case or as per customer required MRJ-Laser mini laser engraving machine for sale The outside, we adopt plywood case, which is fumigation free. In the middle is covered with thick sponge to protect the machine from shaking. Inside this is covered by thickening plastic bag for waterproof.;CNC or Not:No;
Laser Source Brand:RAYCUS;Cooling Mode:Air Cooling;
Certification:CE;Warranty:2 Years;
Marking Depth:0.5mm;Marking Speed:14000mm/s;
Key Selling Points:High Safety Level;Single package size:95X55X85 cm;
Condition:New;Warranty:2 Years;
Brand Name:MRJ-Laser;Control Software:EZCAD Software /JCZ;
Application:Laser Marking;Laser Head Brand:None;
Graphic Format Supported:AI,BMP,DST,DWG,DXF,DXP,LAS,PLT,JPEG/PNG/TIF;
Product Description
Model
MRJ-FL-20B
MRJ-FL-30B
Laser Power
20W
30W
Laser Wavelength
1064nm
1064nm
Beam Quality
M2<1.6
M2<1.6
Repetition Frequency
20-80KHz
20-80KHz
Marking Field
110x110mm
110x110mm
Marking Depth
≤0.5mm
≤1.0mm
Marking Line Speed
≤8000mm/s
≤14000mm/s
Minimum Line Width
10um
10um
Minimum Character
0.15mm
0.15mm
Repetition Precision
±0.005mm
±0.005mm
Power Consumption
≤600W
≤800W
Maintenance-free Time
100000 hours
100000 hours
Input Power
Single Phase110VAC/220VAC/50-60Hz
Cooling Method
Air Cooling
Air Cooling
Contact us to book your free demo!
Detailed Images


- Sino-Galvo high speed digital scanner, better precision;

- Imported servo motor for higher precison and stability;

- Special design for jewelry and luxury application for high class precision and better resolution;


- Contact us to book your 60 multiple details NOW!

Magnifier enlarge 60 multiple
Normal scanner
Resolution is poor for result.

Magnifier enlarge 60 multiple
MRJ-FL-20B

Resolution is much better.


- New design rotary device, special for ring and bracelet;

- One step to adjust parameter, much easier than traditional rotary device;

- Service time over 5 years by using customized motor.

- Contact us to check more information NOW!
Service

Basic service:

1. 16 Hours online service per day;
2. 24 months warranty per machine;
3. Lifetime technical service per order.

Extra service:

1. Extra visiting service for laser marking machine customer; (NOT for ALL customers)
2. Extra regular machine following per laser marking machine order;
3. Free of charge transportation insurance per laser marking machine;
4. Free of charge for protective products per laser marking machine order;
5.5 years spares parts supply after the machine dropped out of market per laser marking machine.

Contact us to get detailed explanation NOW!

Sample
Related Products

Auto-focus fiber laser marking

Light and small, special designed for jewelry application.

Enclosed fiber laser marking machine

CDRH class 1 enclosure, special designed for jewelry application.

Portable fiber laser marking machine

Most classic fiber laser marking machine for most metal materials.

Click here to contact us if there is no your ideal machine NOW!

Our Factory
FAQ

Q1: How can I get the most suitale laser marking machine for me?

Just contact us
, we will suggest you most suitable laser marking machine according to your information.

Q2: I never use laser marking machine before, is it easy to operate?

Yes, it's extremelt easy! We will send you manual and guide video in English, which can help you to know how to operate the machine. If it cannot figure it out, by using "Teamviewer" online software would be very helpful. Or we can talk by phone, email or other contact ways.

Q3: If the laser marking machine has problem in my place, how could I do?

We could send free parts to you in warranty period if machines have any problem under "normal use".

Q4: This model is not suitable for me, do you have more models available?

Yes, MRJ-Laser supply whole machines in this industry. Just contact us, we will show you more about details.

Q5: What's the guarantee, in case the machine breaks down?

The machine has two years guarantee.

Q6: How about the documents after shipment?

After shipment, we will send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.

Q7: How long is the delivery time?

For standard machines, it would be 7-10 days;
For custom machines according to client's specific requirements, contact us to negotiate.

Q8: How's the payment?

Telegraphic Transfer (T/T).
Special requirement according to your country policy is accepted.

Q9: Do You Arrange Shipment For The Machines?


Yes, we will arrange shipment for you for FOB or CIF price. For EXW price, clients need to arrange shipment by themselves or their agents.

Q10:How is the packing?

Durable wooden case or as per required.

3 layers package: The outside, we adopt plywood case, which is fumigation free. In the middle is covered with thick sponge to protect the machine from shaking. Inside this is covered by thickening plastic bag for waterproof.
