30KV 500PF HV Ceramic Capacitor 30KV 501
-
Supplier: Nantong Huasing Electronics Co., Ltd. -
Region: Jiangsu, China -
Contact: Ms Sophie Huang -
Price: $1.00 / >=10 pieces -
Min. Order: 10 pieces
| Packaging Detail: | Carton Packaging; | Package Type: | Through Hole; |
| Operating Temperature: | -30°C~+85°C; | Application: | General Purpose; |
| Capacitance: | 50PF~30000PF; | Port: | Shanghai; |
| Brand Name: | MX; | Type: | Ceramic Capacitor; |
| Delivery Detail: | 10 days; | Model Number: | CT8G; |
| Rated Voltage: | 10KV~150KV; | Payment Terms: | T/T,Western Union; |
| Supply Ability: | 100000 Piece/Pieces per Month; | Place of Origin: | China (Mainland); |
30KV 500PF HV Ceramic Capacitor 30KV 501
Product Name: High Voltage Ceramic Doorknob Capacitor
Series: MXCT8G
Operating Temperature Range°C:-30~+85°C
Working Voltage Range:10KV~150KV
Capacitance Range:50PF~30000PF
Shapes and Dimensions:
Specification Particulars:
| Rated voltage(KV) Capacitance(PF) | TOL. (%) | Ceramic Dielectric | Dimensions(mm) | Part Number | Similar P/N | Similar P/N | Similar P/N | |||
| D | H | L | M | |||||||
| 30KV 190PF | 10 | N4700 | 20 | 20 | 24 | 5 | CT8G30KVDL191K | DHS4E4F191KC2B | DHS4E4F191MCXB | 715C30KTT19 |
| 30KV 400PF | 10 | N4700 | 20 | 20 | 24 | 5 | CT8G30KVDL401K | 715C30KTT40 | ||
| 30KV 460PF | 10 | N4700 | 20 | 20 | 24 | 5 | CT8G30KVDL461K | DHSF44F461ZD2B | DHSF44F461ZDXB | |
| 30KV 500PF | 20 | Y5U | 27 | 30 | 35 | 5 | CT8G30KVY5U501M | 715C30DKT50 | ||
| 30KV 560PF | 20 | N4700 | 28 | 30 | 26 | 5 | CT8G30KVDL501M | HP30E30561M | ||
| 30KV 590PF | 10 | Z5V | 30 | 20 | 24 | 5 | CT8G30KVDL591K | DHS4E4F591KH2B | DHS4E4F591MHXB | 715C30KTT59 |
| 30KV 780PF | 10 | N4700 | 30 | 20 | 24 | 5 | CT8G30KVDL781K | DHSF44F781ZH2B | DHSF44F781ZHXB | |
| 30KV 820PF | 10 | N4700 | 30 | 20 | 24 | 5 | CT8G30KVDL821K | HP40E30821M | ||
| 30KV 940PF | 10 | N4700 | 30 | 20 | 24 | 5 | CT8G30KVDL941K | DHS4E4F941KL2B | DHS4E4F941MLXB | 715C30KTT94 |
| 30KV 1000PF | 10 | N4700 | 38 | 22 | 26 | 5 | CT8G30KVDL102K | 715C30DKD10 | HP40E30102M | |
| 30KV 1120PF | 10 | N4700 | 38 | 22 | 26 | 5 | CT8G30KVDL112K | HP40E31121M | ||
| 30KV 1500PF | 10 | N4700 | 38 | 22 | 26 | 5 | CT8G30KVDL112K | HP50E30152M | ||
| 30KV 1700PF | 10 | N4700 | 52 | 22 | 26 | 5 | CT8G30KVDL172K | DHS4E4F172KR2B | DHS4E4F172MRXB | 715C30KTD17 |
| 30KV 1800PF | 10 | Z5V | 43 | 32 | 34 | 5 | CT8G30KVDL182K | DHSF44F182ZN2B | DHSF44F182ZNXB | HP50E30172M |
| 30KV 2000PF | 10 | N4700 | 43 | 32 | 34 | 5 | CT8G30KVDL202K | HP50E30202M | ||
| 30KV 2200PF | 20 | N4700 | 52 | 24 | 28 | 5 | CT8G30KVDL222M | |||
| 30KV 2500PF | 20 | Z5V | 52 | 30 | 34 | 5 | CT8G30KVDL252M | DHSF44F252ZR2B | DHSF44F252ZRXB | |
| 30KV 2500PF | 20 | Z5V | 46 | 26 | 30 | 5 | CT8G30KVY5U252M | 715C30DKD25 | ||
| 30KV 2700PF | 20 | N4700 | 52 | 30 | 34 | 5 | CT8G30KVDL272M | DHS4E4F272KT2B | DHS4E4F272MTXB | 715C30KTD27 |
| 30KV 3000PF | 20 | N4700 | 60 | 24 | 28 | 5 | CT8G30KVDL302M | HP60E30302M | HP60E30272M | |
| 30KV 3300PF | 20 | Y5U | 55 | 26 | 30 | 5 | CT8G30KVY5U302M | 715C30DKD33 | HP60E30332M | |
| 30KV 3600PF | 20 | N4700 | 60 | 30 | 34 | 5 | CT8G30KVDL362M | DHSF44F362ZT2B | DHSF44F362ZTXB | |
| 30KV 4700PF | 20 | Y5U | 62 | 30 | 34 | 5 | CT8G30KVY5U472M | 715C30DKD47 | ||
| 30KV 5300PF | 20 | Y5S | 60 | 24 | 28 | 5 | CT8G30KVS532M | |||
| 30KV 20000PF | 20 | Y5V | 60 | 24 | 28 | 5 | CT8G30KVF203M | |||
High Voltage Ceramic Doorknob Capacitor Application:
• Gas lasers
• High-voltage dividers
• Marx generators, Power generators
• High-voltage power supply, DC HV power supplies
• High-voltage coupling devices
• Power line coupling system for Internet & Telecom
• Lightning arresters, voltage distribution systems
• Electron microscopes, synchroscopes
• Electrostatic coating machines
High Voltage Ceramic Doorknob Capacitor Features:
• Excellent behavior on pulse and fast discharge conditions
• Low dissipation factor
• Very low partial discharge
• Excellent voltage characteristic
• Molded type, Screw or Axial Leads available
• Coated and uncoated devices available
Factory
Packing
Contact Us
-
