20' Marine Container with Side Doors Side Wall Open Opening Shipping Container

Product details
Container gross weight:24000kgs;Length (feet):20';
Type:Dry Container;Supply Ability:3000 Unit/Units per Month;
Container Size:20gp 40gp 40hc,53ft;Port:Qingdao;
Place of Origin:Shandong China;Container Color:Customized;
Container side door:4pcs;Model Number:20ft;
Container quality:very good;Packaging Detail:one piece, export package.;
Delivery Detail:within 20 working days after down payment.;Application:Storage container;
Capacity:32CUM;External Dimensions(l x W x H)(mm):6058mm * 2438mm * 2591mm;
Internal Dimensions(l x W x H)(mm):5898mm * 2300mm * 2320mm;Container tare weight:3150kgs;
Side door type:Single door;Brand Name:DFC;
Container length:6058mm;Certification:ISO9001;
Payment Terms:L/C,T/T,Western Union;Container inner capacity:30.5mm;



20' Marine Container with Side Doors Side Wall Open Opening Shipping Container





product description

Standard and certificate:

Containers shall comply with following in their latest editions :

1) ISO/TC-104

668

-

Series 1 freight containers-Classification, external dimensions and ratings

6346

-

Coding, identification and marking for freight containers

1161

-

Specification of corner fittings for series 1 freight containers

1496/1

-

Specification and testing of series 1 freight containers.

Part 1 : General cargo containers for general purposes

830

-

Freight containers-Terminology.

6359

-

Freight containers-Consolidated data plate

2) The International Union of Railway (UIC) code 592 OR.

3) The Customs Convention on the International Transport of Goods(TIR).

4) The International Convention for Safe Containers (CSC).

5) Transportation Cargo Containers and Unit Loads Quarantine Aspects and Procedures by Commonwealth of Australia Department of Health. (TCT)

6) provide certificates from classification society (BV, ABS, GL, CCS, LR, KR).



The specifications of 20’ one side full access containers:

1 Dimension



External Dimensions

Internal Dimensions

Length

6,058 ( 0, -6 ) mm

5,898 ( 0, -6 ) mm

Width

2,438 ( 0, -5 ) mm

2,288 ( 0, -5 ) mm

Height

2,591 ( 0, -5 ) mm

2,254 ( 0, -5 ) mm

2 End Door Opening

Width   ..................

2,280 ( 0,-5 )

mm

Height ...................

2,140 ( 0,-5 )

mm

3 Side Door Opening

Width   ..................

5,700 ( 0,-5 )

mm

Height ...................

2,140 ( 0,-5 )

mm

4 Fork Pocket

Width   ..................

360

mm

Height ...................

115

mm

Center distance .......

2,080

mm

5 Inside Cubic Capacity

                       30.5 cu.m

6 Rating

Maximum Gross Weight ..............

24,000 kg



Maximum Payload     .............

20,850 kg



Tare Weight           ...............

3,150 kg





Applications or special features:

1. The container with one end door and one side full access door;

2. The container can load cargos from end and side door;

3. This container can be used for sea, inland, and railway transportation;

4. It is convenient for loading, lifting, moving.











Our Services

1. we can design similar products in different types according to different customize requirements.

2. arrange transportation for customers.

3. arrange "one way" transportation for "SOC" containers.

4. provide professional consultation services.
