Conductor Material: | Copper; | Temperature Range: | -30℃~+90℃ ; -5℃~+90℃; |
Insulation Material: | PVC; | Gross weight per batch: | 12 KG; |
Certification: | CCC,ISO9001,CE,UL,ROHS; | Rated Voltage: | 300/500V; |
MOQ Capacity: | 100 Meters; | Jacket: | PVC; |
Brand Name: | TaiFeng; | Model Number: | TRVVP; |
Package size per batch: | 10X10X10 cm; | Application: | Air-conditioning system,Office Automation equipment; |
Color: | Black or your request; | Payment: | T/T,L/C,D/A,Western Union; |
Application: | Air-conditioning system,Office Automation equipment; | Item: | Multicore Flexible Shielding Control Drag Chain Cable; |
Place of Origin: | Shanghai China; | Conductor Material: | Copper; |
Insulation Material: | PVC; | Selling Units: | Multiple of 100; |
Package Type: | Wooden drum, Carton box, Roll, Plastic drum; |
Item | 2 cores 1.5mm² TRVVP Multicore Flexible Shielding Control Drag Chain Cable |
Conductor Material | Copper |
Insulation Material | PVC |
Color | Black or your request |
Rated Voltage | 300/500V |
Temperature Range | Fixed installation:-30℃~+90℃ Flexing installation:-5℃~+90℃ |
Application | Air-conditioning system,Office Automation equipment |
MOQ Capacity | 100 meters |
Certification | CCC,ISO9001,CE,UL,ROHS |
Bending radius | Fixed installation:4*external diameter Flexing installation:15*external diameter |
Payment | T/T,L/C,D/A,Western Union |
Applications:
As installation cable, it is used under dry or wet indoor situation, for moving or industrial environment condition, such as machine tool, wooden tool, grinding machine,it has excellent crosstalk resistance property.
Properties:
Water proof, oil resistance, cool resistance, flame resistance, normal working temperature is 40℃. Its bending for life is more than normal installation cable’s.
Standards:
VDE0295 CLASS 5
Technical indicators:
Rated voltage :300/300V
Working temperature : Fixed installation:-30℃~+90℃ Flexing installation:-5℃~+90℃
The minimum bending radius:
Fixed installation:4*external diameter
Flexing installation:15*external diameter
Conductor:
