Hot new product small hay baler with good after service

Supplier: Jiangyin Unitetop Heavy Industry Co., Ltd.
Region: Jiangsu, China
Contact: Ms Helen Cheng
Price: $1600.00 /set
Min. Order: 1 set

Click here to contact

Product details

Power:	11kw;	Packaging Type:	Film;
Dimension(LWH):	size;	Port:	Shanghai;
Delivery Detail:	10 working days after confirm the order.;	Place of Origin:	Jiangsu China (Mainland);
Packaging Material:	film packing;	Type:	Packaging Line;
Warranty:	1 Year;	Operating Speed:	Hour;
Supply Ability:	200 Set/Sets per Month;	Driven Type:	Hydraulic;
Model Number:	Y82;	Packaging Detail:	in nude;
Automatic Grade:	Semi-Automatic;	Brand Name:	Unite Top;
Weight:	5000 kg;	Type:	Round Baler;
Payment Terms:	L/C,T/T;	Condition:	Used;
Certification:	ISO9000 CE;	Voltage:	380V;
Year:	2000;	After-sales Service Provided:	Engineers available to service machinery overseas;
Application:	Machinery & Hardware;

Automatic horizontal 150 tons force hydraulic carton bale press machine

hot style sale vertical waste paper balers used cardboard baler machine scrap with high performance

Y83-6300 Hydraulic aluminum Powder Briquetting Press Machine

Hydraulic scrap metal baler with CE

PRODUCT DESCRIPTION

Hot new product small hay baler with good after service

No.	Parameter name		Parameter content
1	Main pressure cylinder	Model number	YG160/100-1200
		Nominal thrust	250KN
		Process	1200mm
2	Push plate cylinder	Model number	YG80/50-700
		Engineering thrust	60KN
		Process	700mm
3	Container size (L×W×H)		1100×480mm
4	Block size (L×W)		1100×480mm(Highly customizable)
5	Hydraulic system working pressure		12.5MPa
6	Pack weight		100~125kg
7	Motor	Model number	Y180M-6
		Power	15KW
		Rotating speed	970r/min
8	Oil pump	Model number	63YCY14-1B
		Displacement	63r/min
		Nominal pressure	31.5MPa
9	Cycle Time	About 15s
10	Fuel tank capacity	1.2L
11	Operation method	PLC control, manual strapping
12	Machine weight	About 2.5 tons

1).Applications:

Y82 series nonmetal hydraulic baler widely used to compressing and packing the relaxed goods such as cotton, yarn, cloth, hemp, wool and other products.

The compressed package block has the uniform outer dimension and the large density and proportion, which is suitable for container transportation.

2).Features:
1. Packing pressure from 25 tons to 200 tons.
2.This series adopts the upper oil cylinder without the requirements of underground foundation.

Technial Specifications for some models of Y82 series non-metal hydraulic baler
