Flying Dream 212cc Big Bore and stroker Kits for zongshen ZS190 engine-upgrade 212cc cylinder kit for pit bike/dirt bike engine

Supplier: Kunshan Flying Dream Motion Co., Limited
Region: Jiangsu, China
Contact: Mr Aven Zhao
Price: $1.00 / >=10 sets
Min. Order: 10 sets

Click here to contact

Product details

Material:	Steel;	Payment Terms:	T/T,Western Union,Paypal;
Color:	grey;	Supply Ability:	500 Set/Sets per Month;
Port:	Ning Bo;	Product Name:	Motorcycle Cylinder Set;
Certification:	CE;	Packing:	Carton;
Payment:	T/T;	Fit for:	zongshen190cc engine;
Place of Origin:	Zhejiang China;	Warranty:	Guaranteed;
Quality:	A-Class;	MOQ:	10;
Model:	212cc;	Type:	Cylinder Block;
Stroke:	4 Stroke;	Brand Name:	Flying Dream;
Packaging Detail:	Standard export package;

Product Description

Main technical parameters
Engine type	Single cylinder,4-stroke,oil-cooling, camshaft upward tilting(10°)
Displacement(ml)	212.11
Dimension(mmmmmm)	460×325×230
Net weight(kg)	24
Max power(kw/r/min)	13.00kw/8000rpm
Max Torque(N.m/r/min)	16.5/ 6500rpm
Compression ratio	12.2:1
Bore and stroke(mm/mm)	66x62
Ignition method	CDI
Lubrication method	Pressure and Splash
Min fuel consumption(g/kw.h)	≤367
Starting method	electric/kicker starting
Clutch method	Manual Wet Multi-Plate
Gear shift method	Constant mesh, two stage transmission ,5-speed Gearshift

Main performance characteristics
Lubricant Cooling	By using oil cooling technology, the heat load during engine operation is reduced and the service life of engine is prolonged.
Arbitrary gear start	Simple operation, can start at any gear, meet the requirements of rapid start.
Forged piston, piston ring	Forging T-piston, micro-arc oxidation of piston head and printing molybdenum disulfide on skirt improve heat resistance and wear resistance of piston; 0.8 thin ring reduces inertia and wear of piston up and down motion, and improves power output and service life of engine.
Strengthened clutch	Adopting 6-Piece reinforced clutch to meet the requirement of large torque transmission.
Design of spray hole in box	Special spray hole jet oil is set in the box to cool and lubricate the cylinder piston, which can effectively control the temperature of the piston and improve the service life of the engine.
Pressure relief valve	The structure of pressure reducing valve is adopted to reduce the starting moment, start easily and improve the service life of all parts of the starting mechanism.
Five-gear transmission	Rational distribution of transmission ratio of each gear by adopting five-speed transmission.
Imported bearings	Imported TPI bearings are used for box bearings to improve engine reliability.
Quality Research and Development	Designed independently by ourselves, Zongshen collaborative testing and processing, reliable quality.

Specifications

1. quality 212cc cylinder kit suits for all model pitbike, dirtbike,monkey,dax.

2. cylinder kit fit to zongshen190cc engine is available for order

3. warranty 1-3 years.

4. delivery 7-25 days.

Detailed Images
