Payment Terms: | L/C,T/T; | High safety design: | High efficient and comfortable ergonomic space; |
Condition: | New; | Port: | FOB Qingdao; |
Emission Standard: | Euro 2; | Transmission Type: | Manual; |
Delivery Detail: | 15 working days; | Box Dimensions (L x W x H) (mm): | 4100*1710*1730mm; |
Packaging Detail: | in bulk ,nude.CKD,SKD,CBU according to customers' requirements; | Technical equipment leading in market: | Better insulation; |
Supply Ability: | 10000 Set/Sets per Year according to customers' inquiry; | Place of Origin: | China; |
Temperature Range: | -18; | Brand Name: | ISUZU; |
Fuel Type: | Diesel; | Dimensions (L x W x H) (mm): | 5995*1880*1930*2850mm; |
Model: | ZZT5041XLC; | 4*2 refrigerator truck: | 3ton-5ton; |
Horsepower: | < 150hp; | Gross Vehicle Weight: | 4490; |
1.The advantage of Refrigerator Truck for meat / milk/ fish /frozen chicken1).Cooling effect
2).Energy saving
3).Driving Comfort
4).4KH1-TC engine
5).capacity:3 tons-5 tons
6).temperature:-18-20
-----------------------------------------------------------------------------------------------------------------------------
2.The Specifications of Refrigerator freezer Trucks ZZT 5041XLC
MODEL | ZZT5041XLC | ||
CHASSIS | ID NO. | NKR77LLEACJAY/1214024 | |
category | |||
manufacturer | Qingling Motors (GROUP).Co.,Ltd | ||
axle | 2 | ||
wheel basemm) | 3360 | ||
wheel track(front/rear mm) | 1504/1425 | ||
tire size | 7.50-15,7.50R15,7.00-15,7.00-16 | ||
tire | 6 | ||
ENGINE | model | 4KH1-TC | |
manufacturer | Qingling Motors (GROUP).Co.,Ltd | ||
delivery capacity(ml) | 2999 | ||
fuel | diesel | ||
rated power(Kw) | 96 | ||
emission standard | GB17691-2005( EURO) | ||
FRAME | FRONT | type | steel plate spring |
quantity | 8 | ||
BACK | type | steel plate spring | |
quantity | 6+5 | ||
CAR LOAD | dimension parameters | overall dimensions(mm) | 5995*1880/1930*2850 |
L*W*H | |||
interior cargo body dimensions(mm) | 4100*1710*1730 | ||
L*W*H | |||
cubage(m3) | 12.12 | ||
front overhang/rear overhang(mm) | 1015/1620 | ||
quality parameters | approach angle/departure angle(°) | 24/16 | |
curb weight(Kg) | 2815 | ||
rated payload(Kg) | 1545 | ||
gross vehicle weight(Kg) | 4490 | ||
max. speed(km/h) | 100 | ||
Persons in cab (persons) | 2 |
-----------------------------------------------------------------------------------------------------------------------------
We can supply: refrigerated truck body, insulated truck body, dry cargo truck body, plateform truck body, explosion-proof truck body, dump truck body,tank truck body, wing opening truck body, catering truck body, any other special purpose truck and truck body.....etc.
