NEW technology 15lpm PSA oxygen concentrator for impurity

Product details
oxygen output:15L 20L 30L;purity:90+-3%;
Payment Terms:L/C,T/T,Western Union,MoneyGram,paypal;working voltage:220V, 50Hz;
outlet pressure:0.06-0.08 Mpa;Brand Name:globalozone;
Delivery Detail:For sample order would be 3-10 working days after get payment;material:zeolite or aluminum;
Model Number:CH-OX;Port:guangzhou;
Supply Ability:800 Set/Sets per Month;Application:oxygen source for ozone generator or fish farm;
Packaging Detail:Export standard package;Oxygen cylinder:12 towers;
commodity name:oxygen concentrator;Place of Origin:Guangdong China;
Production Rate:15L 20L 30L;



                   NEW technology 15lpm PSA oxygen concentrator for impurity





Oxygen output: 15LPM, 20LPM, 24LPM and 30LPM

Oxygen purity: The equipment produces with 90%±3 purity O2 gas.





Features:

  • The equipment uses with Pressure Swing Adsorption (PSA) technology.
  •  lower cost to save your money and time for transportation cylinders.
  • industrial oxygen concentrator used for aquaculture, welding, cutting or feeding oxygen to ozone machine etc.

  • installed inside: Refrigerant air dryer, oil free air compressor, condenser, in order to give clean dry air to PSA oxygen generation system for extending the life time.

  • Each PSA oxygen generation unit with separate control system



Main parts:



1. Refrigerant air dryer (Filter oil, impurities, humidity in the air before enter into air compressor)



2. Oil free air compressor



3. Condenser (Cool down gas temperature before enter into oxygen generation system)



4. Two towers PSA oxygen generation system



5. Oxygen flow meter (To adjust the oxygen output)



Control system



Ampmeter, Voltmeter, Working led, Power led, On/Off, Oxygen flow meter, Oxygen outlet, Fuse, Power input




Specifications



Model

Unit

GO-015L

GO-020L

GO-030L

Oxygen flow rate

LPM

15

20.00

30.00

Oxygen concentration

%

90.5±3

90.5±3

90.5±3

Output oxygen pressure

Mpa

≤0.1 Mpa

Voltage

V

220

220/380

Power

W

1800

1900

2640

Net Weight

KG

130

150

150

Dimension

cm

72×54×118

94×58×118

























Aquaculture system diagram

                   Packaging
