YDS-2 / 3 / 6 / 10L Frozen Cryogenic Cylinder Liquid Nitrogen Dewar Tank

Product details
Certification:ISO,CE;Warranty:2 years;
Package Preview:https://sc02.alicdn.com/kf/HTB1_IxMLSzqK1RjSZPxq6A4tVXal.jpg_640x640.jpg;Advantage:Long Life;
Selling Units:Single item;Color:White, gray;
After-sales Service Provided:Field maintenance and repair service,Video technical support,Online support;Weight:4.5kg;
Dimension(L*W*H):305mm*550mm;Single gross weight:8 KG;
Name:10L Frozen Cryogenic Cylinder Liquid Nitrogen Dewar Tank;Certification:ISO 9001, CE;
Feature:safe, storage;Neck diameter:50, 80;
Place of Origin:Henan China;Material:Aluminium alloy;
Single package size:35X35X60 cm;Weight:4.5KG;
Capacity:2L-10L;Condition:New;
Application:Lab, Medical;Package Type:1.Export standard packaging. 2. Each packed with insulated cover. 3. one piece in one carton 4. If necessary, wooden case or pallet is available. 5. customer requirements;
Brand Name:ZPX;Applicable Industries:Manufacturing Plant,Food & Beverage Factory,Farms,Restaurant,Home Use,Food Shop,Food & Beverage Shops;
Function:Temperature Keepingcooling Liquid;

YDS-2 / 3 / 6 / 10L Frozen Cryogenic Cylinder Liquid Nitrogen Dewar Tank

Product Description

Liquid nitrogen tank  is a kind of container used to store liquid nitrogen of low temperature. Liquid nitrogen tank have  liquid nitrogen storage tank of storage type and liquid nitrogen transport tank for transport. Storage tank is mainly used for indoor liquid nitrogen storage,  and it can ' t be move for a long distance  in the working stat e.  I n order to  meet the transport requirements,  t ransport tank is  made out with a special shock-proof design.   So t ransport  tank  can be used as storage tank, but also as transport tank.  However, the strong shake or conlision still should be avoided.



Detailed Images






Related Products:









YDS-series products are mainly made up of outer shell, inner vessel, neck tube, multi-layer isolating material and canisters.
1.The outer shell and inner vessel are made of the aluminum alloy plate featuring light weight, high cryogenic strength and corrosion resistance.

2.The neck tube is made of glass-fiber reinforced plastics featuring of high mechanical strength and low heat conductivity.

3.The multi-layer insulation is composed of the reflecting screen of aluminum foils with high reflectivity and insulation material with low heat conductivity and low gas-passing speed to reduce heat radiation.

4.The jacket between the outer shell and inner vessel is of high vacuum to prevent thermal convection. Moreover, an adsorbent with a high adsorbing capacity at the cryogenic temperature is used to ensure the long-term stable and reliable performance of the dewar with more than five-year life service.

YDS-2 / 3 / 6 / 10L Frozen Cryogenic Cylinder Liquid Nitrogen Dewar Tank

Specification

 YDS-2 / 3 / 6 / 10L Frozen Cryogenic Cylinder Liquid Nitrogen Dewar Tank

Company Information

     Xinxiang Zhongpanxin Industry Co., Ltd.. has 18 years of production experience and has a modern enterprise of production, sales, after-sales and one-stop service. With the development of science and technology and the needs of industrial and agricultural production, it will be rapidly promoted and applied, and will show a bright future. With the improvement of liquid nitrogen tank technology and industry reputation, we actively expand the international market, and our products have been exported to more than 20 countries including the United States, Germany, Japan, Turkey, India, Mexico and Vietnam.



Application

1. Molicue Food: Molicue delicacy, molicue ice cream.

2. Animal husbandry industry: preservation of frozen semen or vaccine. Multi-layer vacuum design, storage longer
3. Medical and scientific research: preservation of cells, tissues, fungi virus,and other precious biological samples
4. Beauty industry: Remove moles,remove beverage, advise treat and operate under the professional guidance
5. Stage effects: Stage effects of clouds and smoke when wedding, party, theatre, film and other celebrations
6. Cryogenic treatment: Cryogenic treatment of cutting tools, mechanical parts and Precision components etc.

YDS-2 / 3 / 6 / 10L Frozen Cryogenic Cylinder Liquid Nitrogen Dewar Tank

Packaging & Shipping



Our Services

1. We provide you the friendly English User manual or operating videos for free.
2. 24 hours technical support by email or calling.
3. Warranty: 1 year free, 2-3 years cost price and free technical support always.
4. Free training to make sure you master the operating of our products.
5. Once sent, we will track the product for you every two days until you get the product. When you receive the goods, test and give me feedback. If you have any questions about this issue, please contact us and we will provide you with a solution.

FAQ

1.What is the minimum order quantity (MOQ) of your products?
MOQ;1 pieces
2.How about warranty of your product?
Warranty of our product is 12 months.
3.Do you accept OEM order?
Yes,of course,our factory can make a custom for you.
4.What about your terms of delivery and delivery day?
EXW,FOB,CFR,CIF,DDU.
Normally your order will be sent within 3 days;and for customer order products
in great quantity,7to 15 days.Generally 20-30 days for customer OEM products.
5.How about terms of payment?
T/T 30% as deposit,and 70% before delivery.We'll show you the products and packages
before you pay the balance.
6.What is your terms of packing?
Generally,we pack our goods in neutral white boxes and brown cartons.If you
have legally registered patent,we can pack the goods in your branded boxes after
getting your authorization letters.
7.What is your sample policy?
We can send you the sample for you testing before placing the final order.
8.Do you test all your goods before delivery?
Yes,we have 100% test before delivery.
