trade assurance used diesel concrete mixer price
-
Supplier: Shandong Zeyu Heavy Industry Science And Technology Co., Ltd. -
Region: Shandong, China -
Contact: Mr Heavy Industry ZEYU -
Price: $2800.00 /set -
Min. Order: 1 set
| Reclaiming capacity: | 350L; | Model Number: | JZC; |
| Mixing time: | 40~60s; | Packaging Detail: | standard package in container; |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union; | Supply Ability: | 9 Set/Sets per Quarter trade assurance used diesel concrete mixer price; |
| Condition: | Used; | Mixing Power: | 5.5kw; |
| Charging Capacity: | 560L; | driven power: | diesel; |
| Productivity drum mixer: | 14m3/h; | Discharge Way: | inversion; |
| After-sales Service Provided: | Engineers available to service machinery overseas; | Year: | 2012; |
| Place of Origin: | Shandong China; | Brand Name: | Zeyu; |
| Make: | zeyu; | Speed of Mixing Drum: | 17rpm; |
| Motor Power: | 6.05kw; | Working Cycle Period: | 40-60s; |
| Delivery Detail: | within 5 days after receiving the order; | Outline Dimension: | 2.44*2.3*2.642m; |
| Water Supply Mode: | water pump; | Maximum draggy speed: | 20km/h; |
| Port: | Qingdao; |
trade assurance used diesel concrete mixer price
Main Technical specifications
Discharge volume(L) : 350
Arge volume(L) : 560
productivity(m3/h) :12-14
mixing motor:
Model:Y132S-4
Powe(Kw):5.5
rotate speed(r/min): 1440
water pump motor:
Model:50DWB20-8A
power(Kw):0.55
rotate speed(r/min): 2800
mixing barrel rotate speed(r/min):14.5
Particle size of the largest aggregate (gravel/pebble) mm :40/60
mixing time(S): 35-45
Dimension:2550×2230×3050( on working)
2650*2230*2700 (on transportation)
weight (kg) :1920
Diesel engine Main technical parameters
Model: ZS1115M
Type: horizontal, single-cylinder, four-stroke
Cylinder diameter: 115mm
Piston displacement: 1.195
Rated power: 14.71KW
ISO standard fuel stops power (icfn): 16.18kw
Rated speed: 2200r/min
Cooling: Evaporative
Start: Electric start
Battery: 12V Maintenance-free lead-acid battery brand
Net weight: 195kg
Dimensions: 970 × 463 × 699mm
Generator main technical parameters:
Model: STC-15
Power: 15KW
Current: 27.1A
Poles: 4
Frequency: 50 Hz
Power factor: 0.8
Speed: 1500r/min
Considerate after-sales service & product maintenance. We will provide you with the first-class technology and services to gain your
recognition and trust:
1. Excellent manufacturing team with experience of over 15 years.
2. It can be customized to as your need.
3. Service product design, technical support, product installation, repair and other service as your needs.
4. Long-term cooperated transport company ensure the safe and timely delivery.
5. One-stop service save your precious time.
All your needs can be delivered in an accurate and effective manner. You can contact us anytime.
We are a company specialized in designing and manufacturing various of concrete batching plants, as well as the machine parts. Our
company located in Jinan Shandong Province, it was founded by a group of engineers majoring in concrete batching plants.
We have more than ten years' experience of manufacturing and exporting.
As the origin factory, we offer our clients the most favorable price with considerable service. We sincerely welcome clients all over the
world coming to visit our company.
Q: What kind of products do you have?
1. Stationary concrete mixing station arranges from HZS25 to HZS180
2. Mobile concrete mixing station
3. Concrete mixer machine
4. Portable drum concrete mixer with diesel engine
5. Spare parts including screw conveyor and bolted cement silo
Q: How about your technological support?
1. We own a team of engineers majoring in concrete mixing machines with more than ten years’ experience.
2. In recent years, the company cooperates with some domestic and foreign well-known manufacturers, universities and
design institutes. What’s more, it has developed some products with core competence.
3. We could do personal design for clients as their production demand and their condition.
Q: How is your price?
We are factory not the trading company. There is no media organization between
clients and us. We give customers the most favorable price.
Q: What is your payment way?
We support T/T, 30% deposit after signing the contract and remaining 70% need to be received by delivery.
Q: How about your after-sale service?
Engineers go abroad for installation, teaching and maintenance.
Q: How long is the quality guarantee period?
Our quality guarantee period is 12 months.
-
