Wireless Rate: | 300Mbps; | Single package size: | 14.6X9.7X2 cm; |
Single gross weight: | 0.026 KG; | Package Type: | 1. Standard carton packing 2. Custom Packing.; |
Brand Name: | Dusun; | Standard: | IEEE802.11n,IEEE802.11g,IEEE802.11b; |
Chipset: | Reatek RTL8192eus; | Transmission Rate: | 300Mbps; |
Selling Units: | Single item; | Frequency Range: | 2.4G; |
Interface Type: | USB2.0; | Place of Origin: | Zhejiang China; |
Model Number: | 3505B; |
Feature:
· Wireless Standards: IEEE 802.11n/g/b. RTL8192CU Chipset, 2.4GHz Enhanced 300Mbps Wireless data transmission rate,wide range and ultra speed.
· Wide Compatibility: Perfect for PC Laptop Desktop, Support Windows 10/8.1/8/7/XP/Vista, Mac OS 10.4-10.12.2, Linux.
· Internal Antenna & Save Space: The internal omni-directional antenna for increased coverage and stability, easy to carry and no space occupation with mini size.
Software Specification | |
Standard | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Chipset | Realtek 8192EUS |
Wireless Speed | 11n: Up to 300Mbps 11g: Up to 54Mbps 11b: Up to 11Mbps |
Frequency Range | 2.4-2.4835GHz |
Wireless Transmit Power | 20dBm(MAX EIRP) |
Modulation Type | OFDM/CCK/16-QAM/64-QAM |
Receiver Sensitivity (without Standards antenna) | 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER |
Work Mode | Ad-Hoc, Infrastructure |
Wireless Security | 64/128 bits WEP WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) |
Support Operating System | Windows XP/Vista/Win 7/Win 8/Linux/ MAC |
Hardware Specification | |
Interface | USB2.0 Hi-Speed connector |
Operating Temperature | 0oC~40oC (32oF~104oF) |
Storage Temperature | -40oC~70oC (-40oF~158oF) |
Relative Humidity | 10% ~ 90%, non-condensation |
Storage Humidity | 5%~90%, non-condensing |
Dimensions | 17.5*11*1cm ( L*W*H) Packaging |
DUSUN, founded in 2005, is a professional manufacturer dedicated to the research, development and manufacturing of intelligent hardware and devices, then goes to the construction of cloud platform and the development of APP application. And Dusun has more than 13 years of experience in the Internet of Things(IoT) industry. So we have the mature resources, R&D team and technologies.
Welcome to Dusun factory, we have a professional team waiting to help you!
