Abrasion resistant PEEK magnetic pump rear casing

Product details
material:PEEK;feature2:eliminating vortex flow;
Port:Dalian;Brand Name:WDF;
Packaging Detail:standard export carton or wood box with bubble pack outside the item for protection.;OEM:available;
feature3:China manufacturer;Model Number:PEEK rear casing;
Payment Terms:L/C,D/P,T/T,paypal;Certificate:ISO;
ODM:avaialale;dimension:customized;
customized:available;feature1:abrasion resistant;
Place of Origin:Jilin China;color:black/nature;
Pump Parts & Accessries:Pump casing;Standard or Nonstandard:Nonstandard;
Supply Ability:5000 Kilogram/Kilograms per Year;Delivery Detail:15-35 working days after receiving the advance.;

Abrasion resistant PEEK magnetic pump rear casing

send inquiry



Product Description

Property

Value

Compressive Strength

120 to 300 MPa, or 17 to 43 103 psi

Density

1.32 to 1.52 g/cm3

Dielectric Constant (Relative Permittivity)

3.2 to 3.3

Dielectric Strength (Breakdown Potential)

20 MV/m, or 500 V/mil

Dynamic Friction Ratio (Coefficient)

0.22 to 0.38

Elastic (Young's) Modulus

4 to 24 GPa, or 0.58 to 3.4 106 psi

Electrical Resistivity Order of Magnitude

3 to 14 10x Ω-m

Elongation at Break

1.5 to 40 %

Flexural Modulus

3.9 to 24 GPa, or 0.56 to 3.4 106 psi

Flexural Strength (MOR)

160 to 345 MPa, or 23 to 50.0 103 psi

Limiting Oxygen Index (LOI)

40 %

Shear Strength

50 to 100 MPa, or 7.2 to 14 103 psi

Specific Heat Capacity

1700 to 1800 J/kg-K

Tensile Strength

100 to 230 MPa, or 14 to 33 103 psi

Thermal Conductivity

0.25 W/m.K

notch test

55 kJ/m2

Glass temperature

143 °C

melting point

343 °C

Water Absorption (after 24 Hours)

0.06 to 0.1 %

Hydrolysis resistance

High. Even against super heated steam.

High-temperature resistance

Working around 260 ℃ for long term.

Body compatibility

Friendly. Can be implanted into body according to USA FDA regulations.

Chemical stability

High. Only soluble in concentrated sulfuric acid.

Standard

Meet EU & USA FDA regulations. Can come into contact with foodstuffs.

+

material

PEEK

property

High tensile

High temperature resistant

High abrasion resistant

High fatigue resistant

Environmentally friendly

Chemical stability

Material properties

We use Victrex PEEK material as priority. PEEK is a high performance engineering thermoplastic which is short for Poly Ether Ether Ketone.

click for more information









Our Services



+

 Shipment

  • We will ship the items within 15-35 working days after receiving the advance.
  • We are not responsible for any accidents, delays or other issues that are caused by the shipping service.
  • Any import fees or charges are the buyer's responsibility.

 Payment term

  •  We accept T/T, L/C, D/P, and Escrow.

 Package

  •   Standard export carton or wood box.
  •   Using bubble pack outside the item for protection.
our advantage



+
After-sale service
  • If the items you purchase from our company are not of perfected quality, simple return to us for replacement or refund.
  • If the items are defective, please notify us within a week after you receive the items.
  • Any item must be returned in original condition to qualify a replacement or refund.
  • If you have any question after sale, please feel free to contact us. We are happy to help.
  • Any colors, any logo acceptable, free sample service, OEM, ODM, shipping, packing or discount, leave an inquiry to know more details.
FAQ



+

 Q1:  Are you a trading company or manufacturer?

·   We are a professional manufacturer for 15 years.

 Q2: Do you accept OEM for customer’s brand?

· Yes, we do, but need MOQ for mass production.

 Q3: Do you have inspection procedure before shipping?

·   Yes, we do, 100% QC inspection before shipping.

 Q4: What’s the delivery time?

·   Within 10-25 days after confirmed order

 Q5: Can you provide free samples?

·  Yes, we can, but samples freight belongs to clients.
