EMM CS275A High Quality Manual Metal Circular Sawing Machine For Sale

Product details
Voltage:120V;Supply Ability:50 Set/Sets per Month;
Port:Ningbo or Shanghai;Feeding length:750 x many times;
Packaging Detail:standard export package;Saw Type:Corded Band Saws;
Center Bore:32;Experience:More than 12 years;
Payment Terms:L/C,D/A,D/P,T/T,Western Union,MoneyGram;Current:10A;
Hs Code:8461500090;Main Product:EMM CS275A High Quality Manual Metal Circular Sawing Machine For Sale;
OD:250 -- 300 mm;



EMM CS275A High Quality Manual Metal Circular Sawing Machine For Sale



Technical Specification and Capacity

Model

CS275SL

CS315SL

CS350SL

CS400SL

Main motor

2/4 pole 2/2.4KW

2/4 pole 2/2.4KW

2/4 pole 2/2.4/3KW

2/4 pole 2/2.4/3KW

Main shaft rotating speed

96/48

88/44

48/19

  38/19



Suitable saw Blade

OD

Φ250 – 300 mm

Φ250 – 350 mm

Φ250 – 370 mm

Φ250 – 400 mm

Center Bore

Φ32

Φ32

Φ32

Φ32

Pin hole

        2 x Φ11x65mm

        PCD

        2 x Φ11x65mm

        PCD

       2 x Φ11x65mm

PCD

       2 x Φ11x65mm

        PCD

Feeding length

750 x many times

Oil pump system

2.2KW,Pole motor, double –ply pump operating pressure

25-35kg/cm

Cooling system

0.09Kw motor, automatic cooling circulation

Compress air

0.0 – 0.9 Mpa 160N/min

Weight

1100 KGS

1300 KGS

1400 KGS

1500KGS

Packing size









Cutting capacity as reference







sawing profile scale



Φ80

Φ110

Φ125

Φ150



60 x 60

90 x 90

110 x 110

125 x 125



60 x 80

90 x 90

110 x 110

125 x 125



60 x 80

90 x 90

110 x 110

125 x 125



Φ38

Φ55

Φ75

Φ100



38

50 x 50

65 x 65

80 x 80



Using special designed clamping mould, according to diameter to cut 2 – 9 pieces /time



     Special mould dies are not standard configuration should make to order







Standard accessories



  1. machine 1 set
  2. oil system
  3. automatic control electrical apparatus system
  4. dig splay feeding length system
  5. maintenance tooling
  6. machine manual book

Our Services

Presale Service

We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.



Service during the Sale

1. We are manned with professional salesmen and technicians to provide the information, technical support and the optimal solutions with high cost performance.



2. Based on the specific requirements of customers and the lead time, we will formulate a rigorous operation process. Through the close cooperation of Commodity Department, Sales Department, Technical Department and the Ocean Shipping Department, we are devoted to timely supplying customers with superior machines.



3. Generally, certain quantity of quick-wear parts will be delivered with the goods. The delivery deadline depends on the specific order, which is usually within 1 to 3 months.



After-Sale Service

1. One year warranty is provided.

2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the

warranty, we only charge for the basic costs of parts.

3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
