LAUNCH fuel injector cleaner/tester CNC-603A/603C nozzle cleaning machine for sell

Supplier: Guangzhou Junliye Import & Export Co., Ltd.
Region: Guangdong, China
Contact: Ms Winnie Chan
Price: $509.00 /set
Min. Order: 1 set

Click here to contact

Product details

Package Preview:	;	weight:	20;
Speed range:	10-9990 rpm; steps: 10 rpm;	Packaging Detail:	Single package size: 444453 cm Single gross weight: 200 kg Package Type: Carton packing Mob: +86-13929594662;
Input power:	230W;	Place of Origin:	China;
Power supply:	AC220V±10%,50/60Hz;AC110V±10%, 50/60Hz;	Type:	Other;
Dimension:	300395475 (mm);	Cleaning power:	100w;
Selling Units:	Single item;	Fuel tank capacity:	4700mL;
Model Number:	CNC-603A/603C,CNC-603A/C;	Brand Name:	LAUNCH;
Single gross weight:	20.0 KG;	Pulse width range:	0.5-25 milliseconds;Step size: 0.1 milliseconds;
Brand Name:	LAUNCH;	Single package size:	44X44X53 cm;

LAUNCH fuel injector cleaner/tester CNC-603A/603C nozzle cleaning machine for sell

LAUNCH CNC-603A CNC-603C Fuel Injector Tester Car Cleaning Machine Test Bench Equipment

Product overview

• new plastic mold

• mechanical and electrical products combined with ultrasonic cleaning technology and micro processor oil pressure control cleaning and testing technology.

• various conditions of the engine can be simulated to clean and test the fuel injection nozzle of the car, and also to clean the fuel injection nozzle and the oil supply system of the car.

Product parameters

Power supply: AC220V ± 10% 50Hz / 60Hz

AC110V ± 10% 50Hz / 60Hz

Input power: 230W

Cleaning power: 100W

Speed range: 10 ~ 9990 rpm; steps: 10 rpm

Time range: 1 ~ 9999s

Pulse width range: 0.5 ~ 25 milliseconds; Step size: 0.1 milliseconds

Fuel tank capacity: 4700mL

Dimensions: 300*395*475 (mm)

Machine weight: 25kg

Functional features

Ultrasonic strong cleaning technology, strong cleaning ability, no removal cleaning;

Uniformity and atomization testing, sealing testing, oil injection testing, automatic cleaning testing;

Microcomputer pressure regulating control technology, stable oil pressure, wide adjustable range, can adapt to the car equipped with various gasoline injection system, and can realize the nozzle cleaning test automation;

Microcomputer automatic control and digital display technology can automatically control the cleaning and testing process and monitor the main state parameters in real time.

Automatic oil discharge control technology can realize automatic oil discharge through program in some testing items or manually discharge oil through control panel after testing.

Product advantage

Innovative three-in-one design, the host, joint box, cleaning box into one;According to the color of the joint, easy to use;Plastic pipe instead of the original glass pipe, transport and use more convenient and safe; It's more compact.
