Low price Electric type underground deep water Borehole Drilling Machine /water well rotary drilling rig for sale

Supplier: Luohe Orange Mechanical Equipment Co., Ltd.
Region: Henan, China
Contact: Ms Jasmine Yuan
Price: $1500.00 /unit
Min. Order: 1 unit

Click here to contact

Product details

Certification:	ISO;	Drilling diameter:	within 120mm;
Warranty of core components:	1 YEAR;	Video outgoing-inspection:	Provided;
Packaging Detail:	Plywod case package for the Low price Electric type underground deep water Borehole Drilling Machine /water well rotary drilling rig for sale;	Dimension(LWH):	7007002900;
Marketing Type:	New Product 2020;	Rod change method:	Full automatic screw thread;
Drilling depth:	80m;	Port:	qingdao,shanghai,tianjin,yiwu ,guangzhou;
Power Type:	Electric;	Local Service Location:	none;
Voltage:	220v;	Key Selling Points:	PORTABLE;
Condition:	New;	After-sales Service Provided:	No overseas service provided;
Applicable Industries:	Building Material Shops,Manufacturing Plant,Construction works ,Energy & Mining;	Weight:	500kg;
Payment Terms:	L/C,D/A,D/P,T/T,MoneyGram;	Package Preview:	;
Supply Ability:	1000 Unit/Units per Month plywood case package;	Machinery Test Report:	Provided;
Warranty:	12 Months;	Core Components:	MOTOR,pump,engine;
Brand Name:	orangemech;	Type:	Rotary Drilling Rig;
Name:	water Borehole Drilling Machine;	Place of Origin:	Henan China;
Showroom Location:	none;	Application:	Water Wells;
Usage:	Water Well;

Low price Electric type underground deep water Borehole Drilling Machine /water well rotary drilling rig for sale

Product Description

HY-120 Electric type 40-200m deep portable undergroud mine water well drilling rigs for sales

Low price Electric type underground deep water Borehole Drilling Machine /water well rotary drilling rig for sale

This machine mainly used for geothermal drilling, farm irrigation , house yard, gardens and water well drilling, drilling diameter is 70-350mm, and drilling depth is 80m to 100m. It also can be used in small building piling, like farmhouse or factory, the drilling diameter can reach 500mm and depth can be more than 100 meter.

The advantage of the water well drilling machine are as below:

1. Light weight, energy saving.
2. Patented product, unique design and simple drilling structure;
3. Easy to transport and can learn how to handle the machine in short time;
4. Can drill through hard stratum, unless thick rock layer ;
5. One person operation, reduce the labor intensity ;
6. High efficiency and work fast.

7. Assure easily operation and long life service life, free maintainance.

Low price Electric type underground deep water Borehole Drilling Machine /water well rotary drilling rig for sale

Technical data

Low price Electric type underground deep water Borehole Drilling Machine /water well rotary drilling rig for sale

Model of drilling machine	HY-120
Drilling machine overall dimension(mm)	7007002900
Weight of Drilling machine (kg)	120
Drill rod diameter (mm)	42
Drill rod length(mm)	1500
Rod change method	Full automatic screw thread
Drilling depth(m)	80
Voltage (V)	220V
Motor power (KW)	DC60V, 1.5KW~2KW
Drilling method	Percussive and rotating type
Pump power (KW)	2.2KW
Drilling hole diameter(mm)	Within Ø 120mm
Hosting height(mm)	2000
Hosting capacity (kg)	500

Completed unit of drilling machine include main engine, tools, 40 meter drill rod, 2 units alloy drilling bit, 1 unit high pressure water pump, 4 meter high pressure water pipe, 1 unit 60V transformer, back seat, water tank and English manual.
