Certification: | & ISO 9001,ce; | Dimension: | 3230*1200*1830 mm; |
Battery Voltage: | 48V; | Place of origin: | Tianjin,China; |
Seats: | 4,3 - 4; | Climbing Ability: | 20%; |
Fuel Type: | Electric; | Single package size: | 288X120X208 cm; |
Packaging Detail: | Steel frame; | Charger: | On board 48V/25A; |
Single gross weight: | 520.0 KG; | Selling Units: | Single item; |
Color: | Customized; | Type: | Electric Golf Car; |
Brand: | ZYCAR; | Max. Speed: | 30km/h; |
Tianjin Zhongyi Electric Vehicle Co.,Ltd. is located in Tianjin, a large comprehensive port city in northern China. The convenient transportation provides a unique geographic advantage for the sales of our electric vehicles to international market. Over years ,we have grown to be a leading electric cars’ manufacturer in China, a high-tech company that integrates R&D, producing and selling for electric vehicle with a production base area of 18,000 square meters. We are dedicated to produce the top quality electric sightseeing bus, electric golf carts, electric classic cars, electric patrol cars, electric trucks, electric fire trucks and various modified custom made models to you with the competitive price and first class after sales service.
As a production-oriented enterprise that meets the development direction of intelligent manufacturing and new energy industry, our company has passed the special equipment production license, ISO9001 certification, ISO14001 certification, SGS certification, BV certification, CE certification.
Ours carts became the advanced specialized off-road vehicle at home and abroad. Furthermore, good traction, high load capacity and climbing ability, convenient, low-carbon and environmentally friendly,make our vehicles achieved a complete success on pollution-free, low-noise, low-cost operation
Container |
General package |
Semi assembled |
Wholly assembled |
|
Qty/20' |
* |
8 |
4 |
|
Qty/40' |
* |
16 |
8 |
|
Qty/40'HQ |
* |
16 |
8 |
|
Performance |
||||
Passenger Capacity |
4 Seats |
|||
Max.Speed |
25-30km/h(adjustable) |
|||
Driving Range |
80km |
|||
Climbing Ability |
<20% |
|||
Braking Distance |
<3.5 |
|||
Mini Turning Radius |
3.5m |
|||
Min.Clearance |
400mm |
|||
Recharge Time |
8-10hours |
|||
Dimension |
||||
L*W*H |
2880*1200*2100mm |
|||
F/R Tread |
855/980mm |
|||
Axle Distance |
1720mm |
|||
Curb Weight |
520kgs |
|||
Standard Configurations |
||||
Motor |
Mahle Brand 5KW AC motor(Germany brand) |
|||
Controller |
Curtis AC Controller (48V 400A)(USA brand) |
|||
Battery |
Huge capacity deep cycle lead-acid battery 8V/piece 6 pieces |
|||
Body & Roof |
Injection molding design separable replacement |
|||
Windshield |
Tempered glass with wiper |
|||
Seats |
Sponge&artificial Leather with flexible two-point belt and three-point belt |
|||
Rear View Mirror |
2 pcs |
|||
Bumper |
Front and Rear bumper |
|||
Tire |
Golf tyre AT23X10.5-12 |
|||
Chassis |
High strength structural steel |
|||
Steering |
Gear steering, auto backlash compensation |
|||
Brake System |
4 wheels hydraulic brake |
|||
Front Axle |
Non Independent Suspension, Leaf Spring + Cylindrical Hydraulic Shock Absorb |
|||
Rear Axle |
Integral Rear Axle, Non Independent Suspension, Spring, Sylinder Type Hydraulic Shock Absorb |
|||
Light System |
Combination front lighting (turning light, high beam, dipped light) rear lighting (turning light, brake light) driving & reverse buzzer. |
|||
Charger |
On board charger |
|||
Dashboard |
Plastic molding instrument board with volt meter, ammeter,electricity indicator, speedometer,electric key switch, radio with blue tooth, storage box, cup holder,turn signal indicator,forward and Revise indicator. |
Q1. What is your terms of packing?
A: Generally, we pack out goods in containers by iron frame. If you have special requirement we can follow.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: It takes about 30 days after receiving your advance payment.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: Since this product is high-value product, we can accept sample by discount. Should the production be large in quantity, we may even consider re-funding for the sample.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
