New design 220 volt 1000 2kw 3kw 5kw power system vertical axis wind generator turbine with CE certificate

Product details
Wheel Diameter:1.2M;Rated Voltage:12/24V;
Supply Ability:3000 Set/Sets per Week;Payment Terms:L/C,T/T,Western Union,Paypal;
Rated Wind Speed:10M/S;Packaging Detail:Carton Package;
Blades Material:Nylon fiber;Type:wind turbine;
Place of Origin:Jiangsu China;Brand Name:GT;
Safety Wind Speed:55M/S;Port:Shanghai;
Number of Blades:3/5;Maximum Power:130W;
Model Number:NE-100S;Top Net Weight:6KG;
Start-up Wind Turbine:2M/s;Rated Power:100W;
Delivery Detail:5 working days;
Introduction

Features
*Low start up steed, high wind energy utilization;
*Easy installation, tube or flange connection optional;
*Blades using new art of precision injection molding, matched with optimized aerodynamic shape and structure, which enhance the wind energy utilization and annual output;
*Body of casting aluminum alloy, with 2 bearings swivel, making it survive stronger wind and run more safety;
*Patented permanent magnet ac generator with special stator, effectively reduce torque, well match the wind wheel, generator and ensure the performance of whole system;
*Using MPPT control can adjust the voltage more effectively.

S Style Wind Turbine



S Type Wind Turbine


Model
NE-100S
NE-200S
NE-300S
NE-100S2
NE-200S2
NE-300S2
NE-400S2
Rated Power
100W
200W
300W
100W
200W
300W
400W
Maximum Power
130W
220W
310W
130W
220W
310W
410W
Rated Voltage
12/24V
12/24V
12/24V
12/24V
12/24V
12/24V
24V
Start-up Wind Turbine
2M/S
Rated Wind Speed
10M/S
11.5M/S
13M/S
10M/S
11.5M/S
13M/S
13M/S
Safety Wind Speed
55M/S
55M/S
50M/S
55M/S
55M/S
50M/S
50M/S
Top Net Weight
6KG
6.2KG
6.5KG
5KG
5.2KG
5.6KG
5.8KG
Wheel Diameter
1.2M
1.3M
1.35M
1.2M
1.3M
1.35M
1.4M
Number of Blades
3/5
Blades Material
Nylon fiber
Generator
Three phase permanent magnet ac synchronous generator
Magnet
NdFeb
Generator Case
Casting Aluminum Alloy
Control System
Electromagnet
Speed Regulation
Automatically adjust wind ward direction
Work Temperature
-40~80℃
Design Life
20 years





M Style Wind Turbine


M Type Wind Turbine


Model
NE-300M
NE-400M
NE-400M2
NE-500M2
NE-500M3
NE-600M4
NE-700M4
NE-800M5
NE-1000M5
Rated Power
300W
400W
400W
500W
500W
600W
700W
800W
1000W
Maximum Power
320W
410W
420W
520W
510W
630W
720W
820W
1050W
Rated Voltage
12/24V
12/24V
24V
24/48V
24V
24/48V
24/48V
24/48V
48V
Start-up Wind Turbine
2M/S
2M/S
2.5M/S
2.5M/S
2M/S
2.5M/S
2.5M/S
2.5M/S
2.5M/S
Rated Wind Speed
11M/S
11.5M/S
11M/S
11M/S
11M/S
11M/S
11M/S
12M/S
12.5M/S
Safety Wind Speed
50M/S
50M/S
45M/S
45M/S
45M/S
45M/S
45M/S
40M/S
40M/S
Top Net Weight
9.2KG
9.5KG
14.5KG
15KG
11.5KG
20KG
21KG
29KG
30KG
Wheel Diameter
1.35M
1.55M
1.7M
1.75M
1.75M
1.85M
1.85M
2.2M
2.4M
Number of Blades
3/5
3/5
3/5
3/5
3
3
3
3
3
Blades Material
Nylon fiber
Generator
Three phase permanent magnet ac synchronous generator
Magnet
NdFeb
Generator Case
Casting Aluminum Alloy
Control System
Electromagnet
Speed Regulation
Automatically adjust wind ward direction
Work Temperature
-40~80℃
Design Life
20 years
L Style Wind Turbine

L Type Wind Turbine



K Style Wind Turbine



G Style Wind Turbine
