By wheel: | 4WD; | Machinery Test Report: | Provided; |
Type: | Wheel Tractor; | Showroom Location: | None; |
Supply Ability: | 500 Unit/Units per Month; | Brand Name: | Huaxia brand; |
Payment Terms: | T/T,Western Union,MoneyGram,trade assurance; | Packaging Detail: | 1.Nude Package: 4 complete units/40GP, 4 complete units with Cabin/40GP -- 2.SKD Iron Frame Package: 16 units/40GP; |
Cabin: | Warm Air or Fan is available; | Tire: | 9.5-24/650-16 or 11.2-24/750-16; |
PTO: | 2 speeds 540/720; | Key Selling Points: | Easy to Operate; |
After Warranty Service: | Video technical support,Online support,Spare parts,Field maintenance and repair service; | Place of Origin: | Shandong China; |
Applicable Industries: | Building Material Shops,Farms,Retail; | Certificate: | ce; |
Color: | Light Green red blue or depend on client's request; | After-sales Service Provided: | Overseas service center available,Free spare parts,Field installation, commissioning and training,Field maintenance and repair service,Video technical support,Online support; |
Option: | Air Brakes, Hydraulic Valve Out, ROPS, Canopy; | Core Components: | Engine; |
Usage: | Farm Tractor; | Roll bar and canopy: | Available; |
Tire: | AG Tire, Paddy Tire, Turf Tire; | Marketing Type: | New Product 2020; |
Transmission box: | 8F+2R; | Rated Power (HP): | 30HP; |
Condition: | New; | Local Service Location: | None; |
Video outgoing-inspection: | Provided; | Port: | Any port in China; |
Engine Brand: | Laidong or Xichai; | Implement: | Loader, Plough, Mower and More Implements as per Client's request; |
Warranty of core components: | 2 years; | Warranty: | 2 years; |
Drive Type: | Gear Drive; |
35HP Tractor Full Specification
Tractor Parameters |
Model |
304 |
|
Drive Type |
4WD |
||
Overall Dimensions L×W×H(mm) |
2860X1220X1380 |
||
Wheel Track(mm) |
Front |
1200 |
|
Rear |
1242 |
||
Wheel Base(mm) |
1730 |
||
Ground Clearancre(mm) |
Under Front Axle |
300 |
|
Under Rear Axle |
345 |
||
Rated Traction Force(N) |
In Paddy Fields |
4950 |
|
In Dry Fields |
6940 |
||
Construction Mass(Kg) |
1560 |
||
Min. Turning Radius(m) |
2.40 |
||
Theoretical Speed(Km/h) |
Forward |
1.28,1.86,2.98,4.50,6.65,9.63,15.45,23.33 |
|
Reverse |
1.29,1.87,3.00,4.53,6.70,9.70,15.56,23.50 |
||
Engine Specifications |
Model |
LD3T30 |
|
Type |
3-cylinder,4-storke cycle,radiator cooling |
||
12-hour Rated Power(Kw/hp) |
22.0/30.0 |
||
Rated Speed(rpm) |
2400 |
||
Bore×Stroke(mm) |
90×95 |
||
Total Displacement(L) |
1.812 |
||
Drive System |
Clutch |
Dual-stage Or Single-stage |
|
Gear Box |
(4+2)×2 Shuttle shift syuchmesh |
||
Main Drive |
One Pair of Spiral Bevel gears |
||
Differential |
Bevel Gear |
||
Differential Lock |
Jaw Lock |
||
Final Transmissions |
Spur Gear, External Gearing |
||
Travelling Mechanism |
Tyre |
front |
6.50-16(stripe pattern) |
rear |
11.2-24(herringbone pattern) |
||
Steering Gear |
Full Hydraulic steering |
||
Brake |
Disk type |
||
Working Device |
Hydraulic System |
Lifting Capacity at 610 mm Behind Lift Point(Kg) |
415kg |
3-point Suspension |
Category:I |
||
P.T.O.Shaft |
Rotating Speed(rpm) |
540/1000 or 540/720 |
|
Spline size |
6-φ35 Rectangular spline |
Factory Advantages:
Factory Scale |
19 years, Over 200 Workers, Factory Area 50,000.00M2 |
Company Technology |
Professional R&D Center, 7 National Patents |
Tractor with different Chassis |
One Cylinder Belt Transmission Tractor(18-28HP), TY Chassis Tractor (18-35HP), HX Chassis Tractor (30-40HP), HX Chassis Tractor(40-55HP). HX Chassis Tractor (100hp-120HP), |
Tractor Transmission |
6+1 Shift Gear Box, 8+2 Shift Gear Box, Creeping Gear Box and Shuttle Gear Box |
Tractor with High quality Engine |
YTO Engine, JD Engine, LD Engine and Xichai engine |
Tractor with Hotsale Hood |
TY Square Hood, DY Hood, other new designed Hood. With Hood R&D Capacity. |
Quality Control System |
Every Materials, Every Parts, Every Assembly Line, Every Process and Every Worker |
Overseas Market |
Canada, Chile, Argentina, Australia, New Zealand, South Africa, Mozambique, Egypt, Algeria, England, Germany, Norway, Netherlands, Albania, Pakistan, Malaysia |
Warranty Period |
24 Months |
Tractor Implements |
Front End Loader, Backhoe Loader, Post hole digger, Fork Lift, Slasher, Rotary Tiller, Splitting machine, Wood logger…… |
High Quality + Competitive Price + Complete Service = MARKET WINNER |
