Ignition System: | CDI; | Dimensions (L x W x H) (mm): | 793*320*996mm; |
Starting system: | Manual; | Cylinders: | 2; |
Engine Position: | OUTBOARD; | Single gross weight: | 47.0 KG; |
Package Preview: | ; | Product: | 2 stroke engines; |
Control System: | Tiller Control; | Packaging Detail: | carton; |
Selling Units: | Single item; | Warranty: | 1 Year; |
Model Number: | T15S; | Engine type: | 2-stroke; |
Displacement: | 246cc; | Condition: | New; |
Engine: | 2 STROKE; | Fuel Type: | Gasoline; |
Color: | yamaha grey; | Weight(kg): | 37.5 KG; |
Single package size: | 132X71X44 cm; |
2 stroke engines specifications | ||
PNT15 | ||
moto type | 2 Cylinder | |
displacement | cc | 246 |
bore*stroke | mm | 56*50 |
gear ratio | 2.08 | |
full throttle speed range | rpm | 4500-5500 |
Output(kw/ps) | 11.0/15.0 | |
Idling rpm | 750+-50 | |
fuel/induction system | 1Carb | |
IGNITION | CDI-E | |
alternator output | 12V/6A | |
starter | Manual | |
Direction system | manual | |
Trim&Tilt | manual | |
Buit-in fuel tank | L | 24 |
gear shift | ||
shaft length | mm/in | S=440/17.3" L=567/22.3" |
dry weight | KG | 40KW |
