Core Components: | PLC,Engine,Bearing,Gearbox,Motor,Pressure vessel,Gear,Pump; | Year: | 2005; |
Packaging Detail: | customized; | Video outgoing-inspection: | Provided; |
UNIQUE SELLING POINT: | Low Maintenance Cost; | Showroom Location: | South Africa; |
After Warranty Service: | Field maintenance and repair service; | Max. Paving Thickness: | 300mm; |
Production Capacity: | 800(t/h); | Payment Terms: | D/A,T/T,Western Union,MoneyGram; |
Hydraulic Pump Brand: | TOSHIBA; | Hydraulic Valve Brand: | TOSHIBA; |
Local Service Location: | South Africa; | Weight: | 50ton; |
Machinery Test Report: | Provided; | After-sales Service Provided: | Field installation, commissioning and training,Field maintenance and repair service; |
Condition: | Used; | Make: | Leeboy; |
Port: | Port of Durban South Africa; | Warranty of core components: | 3 years; |
Power: | 159kw; | Place of Origin: | South Africa; |
Marketing Type: | Ordinary Product; | Warranty: | 1 Year; |
Applicable Industries: | Hotels,Building Material Shops,Construction works ,Energy & Mining; | Dimension(L*W*H): | 7300*9500*3800mm; |
Supply Ability: | 50 Unit/Units per Month; | Engine Brand: | MITSUBISHI; |
MODEL: | SRP90S plus | SRP95M plus |
Base Paving Width (m) | 3-5.7 | 2.5 |
Maximum Paving Width (m) | 9 | 9.5 |
Maximum Paving Thickness (mm) | 350 | 350 |
Paving Speed (m/min) | 0-18 | 0-18 |
Travel Speed (km/h) | 0-2.4 | 0-2.4 |
Hopper Capacity (t) | 15 | 15 |
Theoretical Productivity (th) | 850 | 850 |
Camber Adjustment(%) | -1 - +3 | -1 - +3 |
Climbing Ability (%) | 20 | 20 |
Vertical Flatness (mm/3m) | <2 | <2 |
Horizontal Slope Error (%) | ±0.02 | 0.02 |
Density Distribution Error (%) | <5 | <5 |
Heating Method | Gas heating | Gas heating |
Lubrication Method | Centralized Lubrication | |
Diesel Engine | Deutz BF6M1013EC |
BF6M1013EC/ Shangchai SC8D190G2B1 |
Power 0utput | 148 | 148/140 |
RPM | 2300 | 2300 |
Screed | AVS9030D | DVM9525Q |
Vibration Speed (r/min) | 0-1470 | 0-1470 |
Vibration Distance (mm) | 4 | 3 ,5,7.9 |
Secondary Vibration Distance (mm) | - | 0,3,6,9,12 . |
Vibration Frequency (Hz) | 0-50 | 0-50 |
Machine Weight (t) | 24 | 22 |
Maximum Operating Weight (t) | 29 | 30 |
External Dimensions LxWxH(mm) | 7800x9000x3800 | 7300x9500x3800 |
Transport Dimensions LxWxH(mm) | 7800x3000x3360 |
7300x3000x3360 |
