10HP 20HP 30HP 50HP refrigerated air dryers refrigerant gas r22 air conditioning compressor

Product details
Cooling method:water-cooling compressed air dryer;Model Number:refrigerated air dryer;
Delivery Detail:5~8 work days refrigerated air dryers;Type:Air Dryer,refrigerated compressed air dryer;
Port:Shenzhen;Cooling water inlet temperature:<=32℃;
Warranty:1 year compressed air dryer;Packaging Detail:wooden case, 1 set /wooden case refrigerated air dryers;
Inlet pressure:0.4~1.3 Mpa refrigerated air dryers;Refrigerant: refrigerant gas r22;
Place of Origin:Guangdong China;Inlet temperature:<=45℃ refrigerated air dryers;
Payment Terms:L/C,T/T,Western Union;Supply Ability:10000 Set/Sets per Month;
Pressure drop:<=0.03Mpa refrigerated air dryers;Dew point:2~10℃ compressed air dryer;
Brand Name:ZAKF refrigerated air dryers;Cooling water inlet pressure:0.2 ~ 0.4 Mpa refrigerated air dryers;
Product Description

Inlet pressure 0.4 ~ 1.3 Mpa 10.7 Nm3 / min water-cooling refrigerated air dryer wholesale

Generally we have air -cooled , water cooled, high/normal-temperature air cooled, high/normal temperature water cooled different style.

1.High efficient air to air heat exchanger. When the temperature of compressed air rises, it will reduce the related humidity of compressed air, it will benefit to the metal corrosion.compressed air dryer
2.High efficient evaporator. The aluminum foil wing connected to the copper pipe to expand the heat transferring area in airside. (it is similar to air conditioning that used at home). Thus ensure the high efficient heat transferring.
 3.High efficient water separator. The good performance can avoid the water evaporatation again, it is important to guarantee the dry effect of freeze dryer. compressed air dryer

Refrigerated compressed air dryer technical parameters(water-cooling)
Mold
AD-10HTW
AD-20HTW
AD-30HTW
AD-40HTW
AD-50HTW
AD-60HTW
AD-80HTW
AD-100HTW
Capacity(Nm3/min)
10.7
25
33
45
55
65
85
110
Compressor Power(HP/KW)
3/2.5
5.0/4.0
6.5/5
10/7.5
12/7.5
12/7.5
20/15
24/15
cooling water circulation volume(m3/h)
3.0(1.8)
7.2(3.6)
11.2(5.9)
14.5(7.2)
19.5(9.2)
21.8(10.8)
25.5(12.4)
29.5(14.6)
voltage(V/Hz)
380/50
380/50
380/50
380/50
380/50
380/50
380/50
380/50
Air Connections
ZG2
DN80
DN100
DN100
DN125
DN125
DN150
DN150
condenser water pipe diameter
ZG1
ZG1.5
ZG1.5
ZG1.5
ZG1.5
ZG1.5
ZG2
ZG2
Dimensions (L*W*H)(mm)
1180
1400
1650
1850
2100
2150
2420
2750
670
750
950
850
920
980
1340
1340
1080
1240
1590
1630
1645
1755
1900
2004
Weight(kg)
195
350
560
720
800
1040
1600
2200
Certifications
Packing & Delivery
Packaging
Size
1180(L) X670(W) X 1080(H)(MM)
Weight
195KG



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Our Company

other key words:

 refrigerated air dryers, Secador de Refrigeração , refrigeration compressor,
compressor refrigerator, compressor air conditioner, air conditioning compressor
refrigerant gas r22, ge refrigerator parts, compressor air conditioner

.

Related Products

Products Name with link

91.8% Response Rate

Products Name with link

91.8% Response Rate

Products Name with link

91.8% Response Rate

CONTACT US
FAQ

Q1: Are you a factory?

A1: Yes, we are.


Q2: How long is the delivery time?

A2: About 5~8 work days. compressed air dryer


Q3: Warranty terms of your machine?

A3: One year warranty for the machine and technical support according to your needs. compressed air dryer

Q4: What about the voltage of products? Can they be customized?
A4: Yes, of course. The voltage can be customized according to your equirement. compressed air dryer

Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly welcome.
