Machinery Test Report: | Provided; | Port: | Shanghai; |
Warranty of core components: | Not Available; | Weight: | 9.2KG; |
Brand Name: | ROGYI; | Place of Origin: | Shanghai China; |
Core Components: | other; | Function: | CUT; |
Rated Current: | 10-50 A; | Video outgoing-inspection: | Provided; |
Dimensions: | 385*155*295; | Supply Ability: | 8000 Piece/Pieces per Month CUT50D; |
Key Selling Points: | Multifunctional; | Payment Terms: | L/C,T/T,Western Union,Paypal; |
Applicable Industries: | Hotels,Building Material Shops,Manufacturing Plant,Retail,Construction works ; | Showroom Location: | None; |
Warranty: | Unavailable; | Weight (KG): | 9.2 KG; |
Condition: | New; | Marketing Type: | New Product 2020; |
After Warranty Service: | Online support; | Packaging Detail: | Plastic film and Expand Aple Polyephylene foam inside, and Corrugated paper carton and Plastic stretch wrap outside.; |
CUT50D: | CUT50D; | Certification: | CE, CCC, ISO9001; |
Local Service Location: | None; | Usage: | CUT; |
Input Voltage: | 1-ph AC 110v or 220v±10% V; |
1,Mosfet inverter and precision constant current feedback. control techonlogy, soft switch.100kHz of cutting frequency
2. Wide working voltage range,strong adaptability to electricity power grid, high ability of interference resistance,automatic voltage compensation, stable cutting current and steady arc.
3.Compact structure,portable ,energy saving easy for maintenance.
4,For'D" series with 11/220 duel voltage input, air cool,automatic input voltage shift,secondary boost for arc stricking
Model Specification |
CUT 50D |
|
Power supply voltage |
1-ph AC 110v or 220v±10% V |
|
Power frequency |
50~60 Hz |
|
Power supply capacity |
6.0 kVA |
|
Rated input current |
25 A |
|
No-load voltage |
230 V |
|
Output current range |
10-50 A |
|
Output voltage |
102 V |
|
Duty cycle |
60% |
|
Efficiency |
85% |
|
Tip hole diameter |
1.0 mm |
|
Arc striking model |
Touch |
|
Cosφ (η) |
0.93 |
|
Air pressure |
0.4 MPa |
|
Cutting thickness |
Steel |
1-12 mm |
Aluminum |
1-8 mm |
|
Copper |
1-6 mm |
|
Air flow |
110 L/min |
|
Insulation grade |
B |
|
Protection grade |
IP 21 S |
|
Net Weight |
9.4 kg |
|
Dimensions (mm) |
385*155*295 |
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY RONGYI.
* FULL SERVICE AND PARTS BACK UP.
* 12 MONTHS WARRANTY.
The data in the above table is only for reference. Please subject to the nameplate
on the device.
