Network: | 2G/3G/4G Network; | Keywords: | SIM Card for Telecom; |
Size: | 85.5*54 or half card; | Material: | PVC; |
Package Preview: | ; | Supply Ability: | 10000 Piece/Pieces per Day; |
Brand Name: | BEIYUAN; | Chip memory: | 128K; |
Application: | Cell Phone; | Product name: | LTE 4g 128K FDD 2FF/3FF/4FF International SIM card SIM Card; |
SIM Type: | 3-in-1 SIM Card (Nano/Micro/Standard); | Payment Terms: | Western Union,T/T,MoneyGram,Alibaba Trade Assurance; |
Color: | White / 4C Color Printing; | Algorithm: | Milenage/ Comp128-1/2/ 3; |
Place of Origin: | Guangdong China; | Port: | Shenzhen; |
Model Number: | LTE; | Packaging Detail: | 200 cards packed in a inner box
2000/3000/4000/5000 cards packed in a outer box; |
Product Description
Our SIM cards are blank can be programmable, the printing and programming can be customized if customer can provide card design and input data file.
The Blank SIM cards canot be use on equipments directly, need program the cards with real parameters, We can provide the card reader and free software to help you program the cards.
Standard,Algorithm,Certification
1-Support Milenage and XOR algorithm, Matching the standards of GSM11.11, GSM11.12, GSM11.14, GSM11.17.
2- Matching the standard of ISO7816.
3- Modularization design that is convenient to realize new functions .
4- Optimized file management system, which supports file access path selection.
5- STK data encrypt and checkout match the GSM03.48 standard absolutely.
6- Supporting the norm of the China Mobile OTA2,the little assistant of no agony, Mass Storage Telephone Book,Group Sending Short Message etc.
7- Supporting inner backup mechanism to insure the data Integrality.
8- supporting T=0 transmission protocol,Communication velocity supports 372/1 and 512/8.
9- Having the function that against inserting and pulling out of card when power on,and abnormal power off.
10- Supporting the algorithm of DES ,3DES ,COMP128-1 and have protection against attacking mechanism.
11- Supporting the function of the circuitry encrypt and circuitry secrecy,preventing communication data against being stolen or juggled unlawful .And it can be used to check out the data integrality.
12- Agile individuation instructions not only insure the require of safety management but also can satisfy all kinds of Customer’s requires of pluralistic STK functions.
13- Perfect safety function and safety strategy,passed EAL4+safe authentication.
Product Paramenters
Card Model | | LTE USIM Card | | |
Network | | 4G LTE, Compatible with WCDMA and GSM | | |
Algorithm | | Milenage | | |
Printing | | Custom Printing | | |
Programming | | Blank or do programming in factory | | |
Size | | 3-in-1 SIM Card (Nano/Micro/Standard) | | |
Chip Memory | | 128KB | | |
Main character of chip
CPU:
- 8 bit CPU or 16bit CPU
Memory size: 128K
EEPROM:
- single byte read ,write, and wipe
- multi bytes storage(1byte to1page)
- program clock come from vibrate clock that generated by chip itself
- At the normal temperature, can proceed at least 100,000 times erase and write operations.
- EEPROM data endurance more than ten years
- EEPROM program voltage generated in the chip
Serial I/O interface:
- Match ISO/IEC-7816
- asynchronous half duplex transmission protocol
- Two kinds of transmission velocity(372/1 and 512/8)optional
Randomizer:
-8- bit randomizer
Power on reset
- internal power on reset mechanism
Low power work mode:
- SLEEP mode
- CLOCK STOP mode
Safety mechanism:
- Abnormal voltage/frequency detection function, DPA/SPS attacking immunity
Details Images
Certifications
Product packaging
Company Profile
Recommend Products
FAQ
1,How can I get the sample to check your quality?
After price confirmation, you can require for samples to check our product’s quality. If you just need a blank sample to check the design and quality. We will provide you sample for free as long as you afford the express freight.
2,What can I get the price?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your email,so that we will regard you inquiry priority.
3,What is your term of delivery?
We accept EXW, FOB Shenzhen or CIF. You can choose the one which is the most convenient or cost effective for you.
4,What about the delivery time for the mass production?
Honestly, it depends on the order quantity and the season you place the order. For SIM cards, our normal delivery time is 7-9 working days
