Diameter: | 2; | After-sales Service Provided: | Video technical support,Online support; |
Condition: | New; | Warranty: | 1 Year; |
Brand Name: | OEM; | Payment Terms: | L/C,Western Union,D/P,D/A,T/T,MoneyGram; |
Video outgoing-inspection: | Provided; | Usage: | Agriculture; |
Local Service Location: | Tajikistan; | precipitation: | 7.3-92; |
Type: | IRRIGATION SYSTEM; | Place of Origin: | Jiangsu China; |
Port: | QingDao/Shanghai/LianYungang; | interlayer velocity difference: | <20 Y/<15 N/<15; |
Machinery Test Report: | Provided; | chassis: | 10.0/75 -15.3; |
Warranty of core components: | 1 Year; | Core Components: | PLC,Engine; |
traction height: | 300- 500; | ground clearance: | 300; |
car climbing: | 20; | Showroom Location: | None; |
Material: | Rubber; | nozzle type: | PYC75; |
Supply Ability: | 200 Bag/Bags per Month; | Marketing Type: | New Product 2020; |
Applicable Industries: | Building Material Shops,Machinery Repair Shops,Farms,Home Use,Printing Shops; | nozzle car track: | 1300-1500; |
Key Selling Points: | Water turbine drive; |
Project | Sseries Model | |||||||
unit | JP32 JP32/D | JP40 JP40/D | JP50 JP50/D | JP65 JP65/D | ||||
interlayer velocity difference | % | <20 D/<15 | <20 D/<15 | <20 D/<15 | <20 D/<15 | |||
precipitation | mm | 5-30 | 5-30 | 6-44 | 8-50 | |||
nozzle type | / | PYK20 | PYK30 | PYK40 | PYC50 | |||
nozzle height | mm | 800 | 800 | 1000-1800 | 1300- 2800 | |||
nozzle car track | mm | 300 | 500 | 600 | 1300 | |||
car climbing | % | 20 | 20 | 20 | 20 | |||
traction height | mm | / | / | 300 | 300- 500 | |||
ground clearance | mm | 200 | 200 | 300 | 300 | |||
chassis | / | 4.00-8 | 150-8 | 145-12 | 165/70 R-13 | |||
wheel tire rim maximum width | mm | 840 | 1030 | 1580 | 2000 |
Project | Uint | Series Model | ||||||
JP75 JP75/D | JP90 JP90/D | JP110 JP110/Y | JP125/Y | |||||
interlayer velocity difference | % | <20 D/<15 | <20 D/<15 | <20 Y/<15 N/<15 | <15 N/<15 | |||
precipitation | mm | 8-50 | 8-50 | 7.3-92 | 10-100 | |||
nozzle type | / | PYC50 | PYC50 | PYC75 | PYC75 | |||
nozzle height | mm | 1300- 2800 | 1300- 2800 | 2000- 3000 | 2000- 3000 | |||
nozzle car track | mm | 1300 | 1300 | 1300-1500 | 1300-1500 | |||
car climbing | % | 20 | 20 | 20 | 20 | |||
traction height | mm | 300- 500 | 300- 500 | 300- 500 | 300- 550 | |||
ground clearance | mm | 300 | 300 | 300 | 300 | |||
chassis | / | 185R 14c | 10.0/80 -12 | 10.0/75 -15.3 | 10.0/75 -15.3 | |||
wheel tire rim maximum width | mm | 2000 | 2310 | 2400 | 2510 |
Project | UnIt | Series Model | ||||||
JP32 JP32/D | JP40 JP40/D | JP50 JP50/D | JP65 JP65/D | |||||
PE pipe diameter | mm | 32 | 40 | 50 | 65 | |||
PE pipe length | m | 70-100 | 90-120 | 150-250 | 200-350 | |||
into the machine working pressure | MPa | 0.3-0.5D /0.2-0.4/ | 0.3-0.6D /0.25-0.5/ | 0.4-0.78D/ 0.35-0.68/ | 0.5-1.0D/ 0.4-0.9/ | |||
nozzle pressure | MPa | 0.15-0.3 | 0.15-0.3 | 0.2-0.4 | 0.2-0.6 | |||
nozzle diameter | mm | 6-10 | 8-12 | 9-16 | 14-18 | |||
flow rate | m7h | 3-6 | 5-9 | 5-19.7 | 11-31 | |||
range | m | 12-18 | 12-18 | 19-30 | 28-43 | |||
spray width | m | 20-30 | 20-30 | 32-51 | 47-74 | |||
combination uniformity coefficient | % | ≥85 | ≥85 | ≥85 | ≥85 |
Series Model | ||||||||
JP75 JP75/D | JP90 JP90/D | JP110 JP110/Y | JP125/Y | |||||
PE pipe diameter | mm | 75 | 90 | 110 | 125 | |||
PE pipe length | m | 250-450 | 300-450 | 300-500 | 200-330 | |||
into the machine working pressure | MPa | 0.5-1.0D/ 0.4-0.9/ | 0.5-1.0D/ 0.4-0.9/ | 0.55-1.25 Y/0.5-1.0 N/0.5-1.0 | 0.55-1.25 Y/0.5-1.0 N/0.5-1.0 | |||
nozzle pressure | MPa | 0.3-0.6 | 0.4-0.6 | 0.5-0.8 | 0.5-0.8 | |||
nozzle diameter | mm | 16-22 | 20-26 | 24-32 | 28-36 | |||
flow rate | m7h | 13-38 | 17-52 | 45-106 | 68-130 | |||
range | m | 28-43 | 35-52 | 45-68 | 55-72 | |||
spray width | m | 47-74 | 60-90 | 77-116 | 95-124 | |||
combination uniformity coefficient | % | ≥85 | ≥85 | ≥85 | ≥85 |
