Payment Terms: | L/C,T/T; | Place of Origin: | Jiangsu China; |
Port: | Shanghai; | Brand Name: | HANMEY; |
Finishing: | Powder; | Type: | Garden Cultivator; |
Supply Ability: | 200 Set/Sets per Month; | Packaging Detail: | steel crate; |
Cultivator Type: | Hoes; | Feature: | Heavy Duty; |
Material: | Metal; | Model Number: | IGN-90 IGN-100 IGN-105 IGN-125 IGN-135 IGN-150 IGN-180; |
MODEL | IGN-90 | IGN-100 | IGN-105 | IGN-125 | ||||
SPECIFICATION | Inch | Metric | Inch | Metric | Inch | Metric | Inch | Metric |
Structure Weight | 551lb | 250kg | 573lb | 260kg | 584lb | 265kg | 628lb | 285kg |
Tilling Width | 2.93' | 895mm | 3.26' | 995mm | 3.43' | 1045mm | 4.08' | 1245mm |
Tilling Depth | 5.91" | 150mm | 5.91" | 150mm | 5.91" | 150mm | 5.91" | 150mm |
PTO Turning Speed | 540r/min | 540r/min | 540r/min | 540r/min | ||||
Tractor HP | 16-20hp | 18-22hp | 20-28hp | 25-30hp | ||||
MODEL | IGN-135 | IGN-150 | IGN-180 | |||||
SPECIFICATION | Inch | Metric | Inch | Metric | Inch | Metric | ||
Structure Weight | 662lb | 300kg | 706lb | 320kg | 772lb | 350kg | ||
Tilling Width | 4.41' | 1345mm | 4.90' | 1495mm | 5.89' | 1795mm | ||
Tilling Depth | 5.91" | 150mm | 5.91" | 150mm | 5.91" | 150mm | ||
PTO Turning Speed | 540r/min | 540r/min | 540r/min | |||||
Tractor HP | 25-30hp | 30-50hp | 40-75hp |
