Overall Operating Weight
|
8200KG
|
Final Reducer
|
Single Stage Final Reducer
|
Transport Dimension
|
Rated Loader of Axle
|
8/18.5t
|
|
L*W*H
|
6120×2410×3763mm
|
Transmission System
|
|
Wheel base
|
2248mm
|
Torque Converter
|
|
Min. Ground Clearance
|
300mm
|
Model
|
YJ280
|
Bucket Capacity
|
1.0m3
|
Type
|
Single-stage Three Elements
|
Breakout Force
|
38KN
|
Max. Efficiency
|
84.40%
|
Loading Lifting Capacity
|
2500KG
|
Inlet Pressure
|
0.4Mpa—0.55 Mpa
|
Bucket Dumping Height
|
2742mm
|
Outlet Pressure
|
1.2Mpa—1.5 Mpa
|
Bucket Dumping Distance
|
1062mm
|
Cooling Method
|
Oil-cooling Pressure Circulation
|
Digging Depth
|
52mm
|
Gearbox
|
|
Backhoe Capacity
|
0.3 m3
|
Type
|
Fixed Shaft Power Transmission
|
Max. Digging Depth
|
4082/4500/5300mm
|
Oil Pressure of Clutch
|
1373Kpa—1569 Kpa
|
Swing Angle of Excavator Grab
|
190o
|
Gears
|
Two Gears Ahead, Two Gears Astern
|
Max. Pulling Force
|
39KN
|
Max.Speed
|
30Km/h
|
Engine
|
Tyre
|
||
Model
|
CUMMINS 4BTA3.9—C100
|
Model
|
14-17.5/19.5L-24
|
Type
|
In Line Direct injection Four-Stroke and Injection Combustion Chamber
|
Pressure of Front wheel
|
0.22 Mpa
|
Cylinder-Inside Diameter*Stroke
|
4-102×120
|
Pressure of Back Wheel
|
0.22 Mpa
|
Rated Power
|
74KW
|
Brake System
|
|
Rated Speed
|
2200r/min
|
Service Brake
|
Air Over Oil Caliper Brake
|
Min. Fuel Consumption
|
≤216g/km.h
|
|
External Type
|
Max.Torque
|
≥410N.M/1500r/min
|
|
Self-regulation
|
Displacement
|
3.9L
|
|
Self-balance
|
Steering System
|
Emergency Brake
|
Operation Power Implementing brake
|
|
Model of Steering Device
|
BZZ5-250
|
|
Manual Operation Power Terminating Brake
|
Steering Angle
|
±36 o
|
Hydraulic System
|
|
Min. turning radius
|
6581mm
|
Digging Power of Excavator Grab
|
46.5KN
|
Pressure of the system
|
18Mpa
|
Digging Power of Dipper
|
44KN
|
Axle
|
Bucket Lifting Time
|
6.8S
|
|
Manufacturer
|
Feicheng Axle Factory
|
Bucket Lowering Time
|
3.1S
|
Main Transmission Type
|
Double Reduction
|
Bucket Discharge Time
|
2.0S
|
