Customized support: | OEM; | Package Preview: | ; |
Single gross weight: | 13.572 KG; | test range: | 10,000-2,000,000 mpas; |
Warranty: | 1 year; | Keyword: | viscometer, brookfield viscometer, rotational viscometer; |
Net Weight (kg): | 6.8 kg; | Selling Units: | Single item; |
Model Number: | RM viscometer, viscometer price; | Name: | brookfield price digital rotational viscometer; |
Outline Dimension (mm): | 370x325x280 mm; | Single package size: | 52X29X45 cm; |
Gross Weight (kg): | 9 kg; | Packaging Detail: | DV-1 NDJ-8s 5s brookfield price digital rotational viscometer; |
Min. Order: | 1 pc by Air or 10 pcs by Ship; | Place of Origin: | Shanghai, China; |
H.S. Code: | 9027; | Delivery Date (<10 pc): | Within 1 Week After Receiving Payment; |
Power: | Electronic; | Brand Name: | WJ viscometer, rotational viscometer; |
Packing (mm): | 400x360x310 mm; |
Model | RV-1S(NDJ-5S) | RV-2M(NDJ-8S) | RV-2T(DV-1) | ||
Measurement Range | 1~100,000mPa.s (Cps) | 1~2,000,000mPa.s (Cps) | |||
Spindles | No.1, 2, 3, 4 Optional : No.0 (Only No. 0 spindle can test 1-10mpa.s) | ||||
Temperature probe | No | No | Yes | ||
Speed | 6, 12, 30, 60 rpm/min | 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 rpm/min | |||
Accuracy | ±2% (non-newtonian liquid) | ||||
PC Software | No | No | Yes | ||
RS232 | Yes |
Model | RV-6M (NDJ-9S) | RVDV |
Measurement Range | 1~6,000,000mPa.s (Cps) | 10-13,000,000mPa.s (Cps) |
Spindles | No.1, 2, 3, 4 Optional : No.0 (Can test 1-10mpa.s) | No.1, 2, 3, 4, 5, 6, 7 (Cannot use No. 0 Spindles) |
Speed | 0.1, 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 rpm/min | 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 rpm/min; 0.5, 1, 2, 2.5, 4, 5, 10, 20, 50, 100 rpm/min; 0.5, 1, 2, 2.5, 4, 5, 10, 20, 50, 100 rpm/min; |
Accuracy | ±2% (non-newtonian liquid) | ±1% (Full measurement range) |
Other accessory | RS232C (Optional: Temperature sensor And PC software) | RS232C; Temperature Sensor; PC Software |
Model | LVDV-2 | LVDV-2S | |
Measurement Range | 1-2,000,000mPa.s (Cps) | 1-2,000,000mPa.s (Cps) | |
Spindles | No. 0, 1, 2, 3,4, | No. 0, 1, 2, 3, 4, 21, 27, 28, 29 | |
Speed | 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 rpm/min 0.5, 1, 2, 2.5, 4, 5, 10, 20, 50, 100 rpm/min | 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 rpm/min 0.5, 1, 2, 2.5, 4, 5, 10, 20, 50, 100 rpm/min 0.5, 1, 2, 5, 10, 20, 50, 100 rpm/min | |
Accuracy | ±1% (Full measurement range) | ||
Other accessory | RS232 Interface; Temperature Sensor; PC software |
Model | RVT1 (Ultra-clear large touch screen) | RVT2 (Ultra-clear large touch screen) | |
Measurement Range | 1~100,000mPa.s (Cps) | 1~2,000,000mPa.s (Cps) | |
Spindles | No. 0, 1, No. 2, No.3, No.4 | ||
Speed | 6, 12, 30, 60 rpm/min | 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 rpm/min | |
Kinematic viscosity | Yes (mm2/s) | Yes (mm2/s) | |
Liquid Density (g/cm3) | Yes | Yes | |
Torque | Yes | Yes | |
shear rate | Yes | Yes | |
Accuracy | ±2% (non-newtonian liquid) | ||
Other accessory | RS232 interface; Temperature Sensor |
Model | RM-1 (NDJ-1) | RM-2 (NDJ-4) | |
Measurement Range | 10~100,000mPa.s (Cps) | 10~2,000,000mPa.s (Cps) | |
Spindles | No.1, No.2, No.3, No.4 Optional : No.0 (No. 0 spindle can test 1-10mpa.s) | ||
Speed | 6 / 12 / 30 / 60 rpm/min. | 0.3 / 0.6 / 1.5 / 3/ 6 / 12 / 30 / 60 rpm/min | |
Accuracy | ± 5% (non-newtonian liquid) |
