TPMS Truck Tire Pressure Monitoring System 0-204Psi 0-14Bar Construction Vehicle TPMS

Supplier: Dongguan Saftire Auto Safety Technology Co., Ltd.
Region: Guangdong, China
Contact: Ms jianfang zhang
Price: $260.00 / 50 - 99 sets
$240.00 / 100 - 199 sets
$100.00 / >=200 sets
Min. Order: 50 sets

Click here to contact

Product details

Model:	Falcon 45	brand:	tire bull
frequency:	433.92 MHz	Installation tool:	Double-row wheels do not remove the wheels to install the sensor
Repeater fixing method:	No damage repair, 10S completion	year:	2007-2009
Voltage:	DC 8~36V	greatest pressure:	14 bar
grade:	Automotive Grade Sensors	Packaging Preview:
Sensor operating temperature range:	-40--125℃	Air Nozzle Connector:	12V1
Number of supported tires:	2--24 wheels	place of origin; place of origin:	Guangdong, China
Communication Interface:	1 CAN bus and 1 RS232 (485 optional)	installation method:	Built-in bundled installation
Protection class:	IP67	port:	Shenzhen
Warranty:	one year	payment terms:	wire transfer
Auto Parts:	Bus and Coach International (BCI)	Packaging Details:	Shipping Neutral Packaging
Sensor design life:	24 hours working conditions 6.1 years	Supply capacity:	7 sets per day

Product Description

Name	technical parameter
battery model	CR 2050
Center frequency	433.92 MHz
stand-by current	﹤0.7uA
Emission current	﹤10mA
High frequency transmit power	>-11dbm (50Ω)
high frequency modulation	FSK
low frequency reception frequency	125KHz±5KHz
Low frequency demodulation mode	ask
Pressure measurement range	0-14bar(0～203PSI)
Pressure Resolution	±2.75 kPa
Pressure measurement accuracy	±7KPa(0℃～70℃)
	±15 KPa (-40℃～125℃)
Temperature measurement range	-40℃～125℃
temperature resolution	±1℃
Temperature measurement accuracy	±2℃(-20℃～70℃)
	±3℃(-40℃～125℃)
range of working temperature	-40℃～125℃
Storage temperature range	It is recommended to store at room temperature
Protection class	IP67
Fire-proof level	94V0
