Material: | PVC | place of origin; place of origin: | Guangdong, China |
Packaging Preview: | structure: | end with bell | |
standard: | UL651 | model: | PVC Pipe Schedule 40 |
port: | Shenzhen/Guangzhou | usage: | for wire protection |
title: | pvc wire pipe | Minimum order quantity: | 1000 |
length: | 10 or 20 feet | Supply capacity: | 1,000,000 pieces per week |
Anti-aging: | Sunlight | brand: | Ryders |
payment terms: | L/C,Western Union,D/P,T/T,MoneyGram,Paypal | type: | heat shrink |
Fire resistance: | V0 | style: | Schedule 40 |
color: | grey |
Numbering. : | pvc wire pipe |
Impact resistance: | Complies with UL651 |
Electrical Characteristics: | Electrical insulation, >1000MΩ, |
Flame Propagation Resistance: | Non-flame spread (V0 class), less than 5 seconds |
Sun resistance: | Yes |
color: | gray, or customized |
print: | permanent |
UL651 pvc electrical conduit | UL651 Electrical Rigid PVC Conduit | |||
transaction size | Schedule 40 Minimum ID | Schedule 80 Minimum ID | ||
1/2 | 0.58 | 0.50 | ||
3/4 | 0.78 | 0.70 | ||
1 | 1 | 0.91 | ||
1-1/4 | 1.34 | 1.23 | ||
1-1/2 | 1.56 | 1.45 | ||
2 | 2.02 | 1.88 | ||
2-1/2 | 2.41 | 2.25 | ||
3 | 3.01 | 2.82 | ||
3-1/2 | 3.49 | 3.28 | ||
4 | 3.96 | 3.74 | ||
5 | 4.98 | 4.71 | ||
6 | 5.99 | 5.65 |
