port: | Lianyungang, Shanghai Port | Supply capacity: | 2000 pieces per day |
Material: | ES quartz glass, IR quartz glass | payment terms: | Letter of Credit, Wire Transfer, Paypal |
Packaging Details: | The inner layer is white foam paper + plastic foam board, and the outer layer is a carton. | brand: | open the net |
place of origin; place of origin: | Jiangsu, China | Volume (ml): | 0.35, 0.7, 1.7, 3.5, 7.0, 10.5, 14.0, 17.5, 35 |
Classification: | other | OEM and OEM: | Yes |
Custom Support: | OBM | Warranty: | 3 years |
model: | KW110 | Path length (mm): | 1, 2, 5, 10, 20, 30, 40, 50, 100 |
Specifications (mm): | 4*12.5*3.5, 45*12.5*7.5, 45*12.5*42.5 | Inner width (mm): | 10 |
1. Scope of application: used in chemical, metallurgy, medical, pharmaceutical, food, environmental protection, power plants, water plants, petroleum and other industries, departments, colleges and universities, laboratories, etc.
2. Material: high-purity quartz powder.
3. Material characteristics: extremely low thermal expansion coefficient, high temperature resistance, high chemical purity, high corrosion resistance, wide light transmission from ultraviolet to infrared, excellent electrical insulation properties.
4. Physical configuration: standard window and wall thickness.
5. Size: As per request.
Product Code:
cat. Do not. |
Material |
Specification H×W×depth (mm) |
Path length (mm) |
Inner width(mm) |
Volume (ml) |
KW104001 |
ES quartz glass (190nm-2500nm) |
45×12.5×3.5 |
1 |
10 |
0.35 |
KW104002 |
45×12.5×4.5 |
2 |
10 |
0.7 |
|
KW-104003 |
45×12.5×7.5 |
5 |
10 |
1.7 |
|
KW-104004 |
45×12.5×12.5 |
10 |
10 |
3.5 |
|
KW-104005 |
45×12.5×22.5 |
20 |
10 |
7.0 |
|
KW-104006 |
45×12.5×32.5 |
30 |
10 |
10.5 |
|
KW-104007 |
45×12.5×42.5 |
40 |
10 |
14.0 |
|
KW-104008 |
45×12.5×52.5 |
50 |
10 |
17.5 |
|
KW-104009 |
45×12.5×102.5 |
100 |
10 |
35.0 |
|
KW-104010 |
Infrared Quartz Glass (250nm-3500nm) |
45×12.5×3.5 |
1 |
10 |
0.35 |
KW-104011 |
45×12.5×4.5 |
2 |
10 |
0.7 |
|
KW-104012 |
45×12.5×7.5 |
5 |
10 |
1.7 |
|
KW-104013 |
45×12.5×12.5 |
10 |
10 |
3.5 |
|
KW-104014 |
45×12.5×22.5 |
20 |
10 |
7.0 |
|
KW-104015 |
45×12.5×32.5 |
30 |
10 |
10.5 |
|
KW-104016 |
45×12.5×42.5 |
40 |
10 |
14.0 |
|
KW-104017 |
45×12.5×52.5 |
50 |
10 |
17.5 |
|
KW-104018 |
45×12.5×102.5 |
100 |
10 |
35.0 |
|
KW-104019 |
Optical glass (340nm-2500nm) |
45×12.5×3.5 |
1 |
10 |
0.35 |
KW-104020 |
45×12.5×4.5 |
2 |
10 |
0.7 |
|
KW-104021 |
45×12.5×7.5 |
5 |
10 |
1.7 |
|
KW-104022 |
45×12.5×12.5 |
10 |
10 |
3.5 |
|
KW-104023 |
45×12.5×22.5 |
20 |
10 |
7.0 |
|
KW-104024 |
45×12.5×32.5 |
30 |
10 |
10.5 |
|
KW-104025 |
45×12.5×42.5 |
40 |
10 |
14.0 |
|
KW-104026 |
45×12.5×52.5 |
50 |
10 |
17.5 |
|
KW-104027 |
45×12.5×102.5 |
100 |
10 |
35.0 |
