Applicable industries: | Hotels, Clothing Stores, Building Materials Stores, Manufacturing Plants, Machinery Repair Stores, Food and Beverage Plants, Farms, Restaurants, Home Use, Retail, Food Stores, Printing Stores, Construction Engineering, Energy and Mining, Food and Beverage Stores, Others, Advertising Companies, outdoor advertising printing shops, clothing bronzing industry, self-adhesive printing and cutting | payment terms: | L/C,Western Union,T/T |
RIP software: | Roland versaworks | Core components: | motherboard |
Mechanical test report: | if | ink: | CMYK Eco-friendly Ink |
usage: | Card Printers, Receipt Printers, Tube Printers, Paper Printers, Label Printers, Cloth Printers, Adhesive Printing and Cutting | Packaging Details: | Wooden case, fumigation-free wooden packaging |
speed: | 10 sqm/hour | Warranty: | 3 months |
Print size: | 736mm | Dimensions (L*W*H): | 2570 x 810 x 1103 mm |
Health status: | used | Auto grade: | automatic |
Local service location: | not any | Main selling point: | long lasting |
Packaging Preview: | Ink Type: | Eco-friendly ink | |
place of origin; place of origin: | Japan | port: | Guangzhou |
color: | 4 colors | Print Head: | with print head |
Voltage: | 220V | Core Components Warranty: | 3 months |
brand: | Roland | After Warranty Service: | Video technical support |
Video external inspection: | if | Supply capacity: | 100 pieces per month |
weight: | 89 kg | Marketing Type: | Hot Products of 2021 |
After-sales service provided: | Online support | printing material: | ECO/PU Paper Body Sticker |
Colors and Pages: | Polychromatic | Print Resolution: | Maximum 1440*1440 Dpi |
automatic grading | automatic |
color and page | Polychromatic |
plate type | Inkjet Printers |
Voltage | AC 220 to 240V |
Warranty | 3 months |
Printer model | VP300i/VP300 |
Specification | VP-540i | VP-300i | |||
How to print | Micro-Pressure Inkjet Mode | ||||
Moderate | width | 210 - 1,371 mm (8.3 - 54 inches) | 182 - 762 mm (7.2 - 30 inches) | ||
thickness | Prints with a maximum paper thickness of 1.0 mm (39 mil) and a maximum line width of 0.4 mm (16 mil) and 0.22 mm (9 mil) when cutting | ||||
Outer drum diameter | up to 180 mm (7 in) | ||||
Reel weight | Up to 30 kg (66 lb) | Up to 20 kg (44 lb) | |||
Kernel diameter | 50.8mm or 76.2mm (2 or 3") | ||||
print/cut width s1 | Up to 1,346 mm (53 in) | Up to 736 mm (29 in) | |||
ink cartridge | type | Dedicated Roland ECO-SOL MAX or FPG2 water-based cartridges | |||
capacity | 220ml or 440ml | ||||
color | Four colors (green, magenta, yellow and black) | ||||
Print Resolution (Print Dot Resolution) | Up to 1,440dpi | ||||
cutting speed | 10 to 300 mm/sec | ||||
knife pressure | 30 to 300 gf | ||||
offset compensation | 0 to 1.5 mm (0 to 0.059") | ||||
Software resolution (while cutting) | 0.025 mm/step | ||||
Distance accuracy (when printing) s2 s3 | The error is less than 0.3% of the taken length ±, or 0.3 mm ±, whichever is greater | ||||
Distance accuracy (when cutting) s3 | The error is less than ±0.4% of ±0.4% or ±0.3 mm of length, whichever is greater. When performing length calibration (and After the "CUTTINGMENU"-"CALIBRATION" operation): the error is less than ±0.2% of the taken length, or 0.1 mm ±, whichever is greater | ||||
Repeatability (while cutting). . . | ± 0.1 mm or less | ||||
Alignment accuracy when printing and cutting | ± 0.5 mm or less | ||||
3 x 6 alignment for printing and cutting after reloading media | The error is less than 0.5% ± or 0.3 mm of the taken length, whichever is greater | ||||
medium heating system s7 | The print heating preset temperature range is 30 to 45 degrees Celsius (86 to 112oF), and the air dryer preset temperature range is 30 to 50 degrees Celsius (86 to 122oF) | ||||
interface | Ethernet (10BASE-T/100BASE-TX, automatic switching) | ||||
Power saving function | automatic sleep | ||||
Power requirements | AC 100 - 120 V 10%, 7.6 A, 50/60 Hz or AC 220 - 240 V 10%, 3.9 A, 50/60 Hz | AC 100 to 120 V 10%, 5.5 A, 50/60 Hz or AC 220 to 240 V 10%, 2.8 A, 50/60 Hz | |||
energy consumption | run | Approx. 1,030 W | about 730 watts | ||
sleep mode | about 14 watts | about 14 watts | |||
noise level | run | 64 dB(A) or less | 64 dB(A) or less | ||
Standby mode | 40 dB(A) or less | 40 dB(A) or less | |||
size | Bring support | 2,310 (W) x 740 (D) x 1,125 (H) mm [90.9 (W) x 29.1 (D) x 44.3 (H)"] | 1,700 (W) x 740 (D) x 1,125 (H) mm [66.9 (W) x 29.1 (D) x 44.3 (H) "] | ||
Weight (with stand) | 112 kg (247 lb) | 89 kg (196 lb) | |||
surroundings | Turn on the power | Temperature: 15 to 32 degrees Celsius (59 to 90oF) (20 degrees Celsius (68oF) or higher recommended) and humidity: 35 to 80% (non-condensing) | |||
Turn off the power | Temperature: 5 to 40 degrees Celsius (41 to 104oF), Humidity: 20 to 80% (non-condensing) | ||||
appendix | Stand, Power Cord, Cutter, Tool Holder, Media Clip, Media Clip, Replacement Cutter, Cleaning Tool Kit, RIP Software and User Manual, etc. |
