Applicable industries: | manufacturing plant | year: | 2021 |
Min. Thickness of Die Block (mm): | 130 mm | Internal space between bars (vertical) (mm): | 230mm |
Core components: | Motor, PLC | Internal space between bars (horizontal) (mm): | 230mm |
Start itinerary: | 130mm | place of origin; place of origin: | Guangdong, China |
color: | green | Mechanical test report: | if |
Voltage: | 380v | Health status: | new |
Ejector stroke (mm): | 130 mm | Type of machine: | Hot Chamber Die Casting Machine |
application: | metal alloy | Fuel tank capacity: | 180L |
Showroom location: | not any | Dimensions (L*W*H): | 2500*1000*1900mm |
Shooting force (kN): | 25kN | type: | Hot Chamber Die Casting Machine |
Weight (kg): | 1400 | Applicable materials: | Zinc alloy |
Die thickness (min~max): | 120~300mm | Ejection force (kN): | 25kN |
Warranty: | 1 year | Marketing Type: | normal product |
Clamping force: | 250KN | Clamping force (kN): | 250kN |
payment terms: | Letter of Credit, Telegraphic Transfer, MoneyGram | feature: | professional |
Video external inspection: | if | Effective hitting weight: | 150~220g |
Main selling point: | easy to operate | Maximum thickness of die base (mm): | 300 mm |
Injection stroke (mm): | 130mm | Core Components Warranty: | 1 year |
Power (kW): | 7.5 |
thing | Specification | thing | Specification |
clamping force | 250KN | 85kg | |
Double cylinder diameter | 55mm | Oil pump flow | 36 L/min |
Tie rod diameter | 40mm | Accumulator volume | 10L |
Opening stroke | 130mm | Fuel tank capacity | 180L |
Tie rod spacing (H*W) | 230*230mm | dry cycle time | 3.5S |
Die thickness (Min~Max) | 120~300mm | Nozzle heating power | 1.2Kw |
Injection cylinder stroke | 70mm | Material melt heating power | 9-12Kw |
Injection plunger diameter | 35~38mm | fuel oil for material | 1.5kg/hour |
ejection force | 25KN | Motor Power | 7.5Kw |
Injection plunger diameter | 60mm | hydraulic | 6~8M per year |
Effective shot weight | 150~220g | Dimensions | 2500*1000*1900mm |
across Stoke | 220mm | machine weight | Ton |
