JC Agras T40 40L Chemical Spraying APAR Agricultural Drone with Binocular Vision Agriculture Drone Sprayer

Product details
battery capacity:30000 mAFunction:One-key take-off/landing, with camera, with remote control, with LED light
Applies to:Agras T40Expand Size:112CM*75CM*85CM
Version:Global versionmodel:JC-AD-40001D
payment terms:Wire transfer, AlipayMaterial:carbon
capacity:40L, 40000 mlusage:Agricultural pesticide spraying drone
place of origin; place of origin:Guangdong, ChinaKey words:Agricultural drone sprayer
Maximum takeoff weight:101KGnet weight:38kg
Packaging Details:Carton and Wooden Boxapplication:heavy agricultural drone
type:agricultural use
Product parameters
title
Agras T40
place of origin; place of origin
China
Total weight (excluding batteries)
38kg
maximum takeoff weight
50kg
Hover Endurance
18 minutes (@30,000 mAh & takeoff weight 50 kg)
7 minutes (@30,000 mAh and 90 kg take-off weight with full canister)
6 minutes (@30,000 mAh and 101kg full tank takeoff weight)
maximum operating speed
6 m/s
The maximum diagonal wheelbase of the fuselage
2,000 mm
Dimensions
2800mm × 3150mm × 780mm (arm and blade unfolded)
1590mm × 1930mm × 780mm (arms unfolded, blades folded)
1125mm × 750mm × 850mm (with arms folded)
Propulsion system KV
Motor 48 rpm/v
propeller diameter
54 inches
Sprinkler System - Water Pump
magnetic pump
Spray tank volume
Full: 40 liters
Max T30 Spreading System 3.0 Weight
50kg
Spreader volume
40L
Nozzle model
LX8060SZ (standard)
T30 Intelligent Flight Battery
BAX501-30,000mAh-52.2V
battery weight
12 kg (approximately)
Capacity/Voltage
30000mAh/52.2V
Omnidirectional obstacle avoidance radar
RD2484R/IP67
rear view radar
RD2484B/IP67
Remote control type
RM700, support T40, T20P
Remote positioning
* GPS+Galileo+Beidou
Remote control display
7.02-inch screen, resolution 1920×1200, brightness 1200 cd/m²
T30 Intelligent Flight Battery Charger
9000W fast battery charging station, fully charged in 9~12 minutes
D12000iE Gasoline Generator
9~12 minutes to fully charge T40 battery
