Application: | Military; | Jacket: | Rubber; |
Supply Ability: | 50000 Kilometer/Kilometers per Month; | Insulation Material: | Rubber; |
Payment Terms: | T/T; | Conductor Material: | Copper; |
Model Number: | YGZ; | Place of Origin: | china; |
Brand Name: | shenyuan; | Packaging Detail: | 100/200/500 meters per coil; Can be packed in coil, reel, drum; Outer packaging: paper cartons, pallet. Port: Shanghai or Ningbo; |
Rated Voltage: | 500/1000V; | Application: | Electic Power, lighting, air conditioning, drying path, auto ignition; |
Color: | White-Blue-Red-Black-Brown-Yellow-Green-Transpanrent-Yellow/Green; | Port: | Shanghai; |
Product name: | high temperature 0.5mm silicone rubber wire 2 core cable; | Insulation: | silicone; |
1) Product: silicone cable
2) Style No.: YGZ/YGZF
3) Size: 0.1sqmm~240sqmm;
4) Rated Voltage: 300/500V; 450/750V
5) Rated Temperature:-60°C~+200°C
6) Conductor: Stranded Tinned plated copper
7) Insulation: silicone rubber or fep/pfa
8) Coated: Silicone rubber
8) Color: red / yellow / blue / white / black / yellow green / brown / orange / purple / green / etc
Product features
*excellent resistance to high temperature
*low temperature resistance
*electrical properties and waterproof
*mildew superior performance
*aging resistance
*Excellent bending performance
*long service life
Applications
*mobile motors
*aviation
*power plants
*petrochemical and other high temperature environment
Section Area mm2 | Conductor construction NO.×mm | Insulation thickness mm | Number of cores | m/coil |
0.2 | 7×0.20 | 0.4 | below 37 cores | 200 |
0.3 | 16×0.15 | 0.5 | 200 | |
0.5 | 28×0.15 | 0.6 | 200 | |
0.75 | 24×0.20 | 0.6 | 100 | |
1 | 32×0.20 | 0.6 | 100 | |
1.5 | 48×0.20 | 0.6 | 100 | |
2.5 | 49×0.25 | 0.7 | 100 | |
4 | 56×0.30 | 0.7 | 2~12 | 100 |
6 | 84×0.30 | 0.7 | 2~10 | 100 |
10 | 84×0.40 | 1 | 2~5 | 100 |
16 | 126×0.40 | 1.2 | 100 | |
25 | 196×0.40 | 1.3 | 100 | |
35 | 494×0.30 | 1.4 | 100 | |
50 | 396×0.40 | 1.6 | 100 | |
70 | 511×0.40 | 1.6 | 100 | |
95 | 760×0.40 | 1.8 | 100 | |
120 | 608×0.50 | 2 | 100 | |
150 | 756×0.50 | 2.2 | 100 | |
185 | 925×0.50 | 2.4 | 100 | |
240 | 1221×0.50 | 2.6 | 100 |
