Automatic rotary casting machine Centrifugal casting machine

Supplier: Shenzhen Kaite Industry Co., Ltd.
Region: Guangdong, China
Contact: Ms Lisa Zheng
Price: $1900.00 /set
Min. Order: 1 set

Click here to contact

Product details

Core components:	PLC, engine, motor	Mechanical test report:	if
easy to use:	Yes	Packaging Details:	Plywood case
product name:	Centrifugal casting machine	port:	Shenzhen, China
Warranty:	1 year	Video external inspection:	if
Marketing Type:	normal product	Key words:	Rotary casting machine
Casting method:	Centrifugal	place of origin; place of origin:	China
application:	Low melting point alloy castings	After-sales service provided:	online
Voltage:	220V/380V/440V	Applicable metal:	Zinc, lead, tin
type:	rubber mold	Weight (kg):	390
Core Components Warranty:	1 year	Main selling point:	easy to operate
Type of machine:	centrifugal casting	Showroom location:	not any
payment terms:	wire transfer	usage:	Zinc Jewelry Casting
Applicable industries:	Clothing Stores, Machine Repair Shops, Manufacturing Plants, Advertising Agencies, Jewelry Industry, Footwear Industry, Promotional Gifts, Fashion Jewelry, Leather Industry, Model Building, 3D Printers, Tin Manufacturing, Souvenir and Religious Item Production, Furniture Accessories, Rapid Prototyping

Centrifugal casting machines are used to produce cast buttons and accessories, imitation jewelry, promotional gifts, medals, buckets, fishing pendants, figurines, etc. in the leather industry and clothing industry, using zinc alloy or tin alloy.

1/. Fully automatic three-station centrifugal casting machine

Model	ATSC12	ATSC14
station	3	3
Maximum die diameter	12"	14”
Die thickness, mm	0-120	0-120
pressure, kg	0-7	0-7
Centrifugal Motor, kW	1.5	1.5
Centrifugation speed, rpm	50-1400	50-1400
Indexing table motor, kW	0.4	0.4
Indexing speed, rpm	50-1400	50-1400
Furnace loading, kg	120 (zinc alloy)	120 (zinc alloy)
Furnace, kilowatts	9	9
Foundry Channel, kW	4	4
options	platform	platform

2/. Automatic centrifugal casting machine

Fully automatic centrifugal casting machine is used to produce precision casting buckles and accessories, imitation jewelry, promotional gifts, medals, statues, etc.

feature:

Compact design, rotary casting and metal melting furnace integrated.
high efficiency.
Automatic feeding, automatic control, precise repeat production,
Effectively save time and labor.
The variable frequency drive adjusts the centrifugal speed from 0-1400 rpm.
Safety protection in the centrifuge area.
Touch screen control panel digital display and settings, speed, spin time and fill time etc.
The PLC sets and controls production cycles, times, speeds and recipes.
Programmer and settings storage.
Automatically diagnose mold loss.
The built-in fan forcibly cools the rubber mold and increases the service life of the mold.
Easy to operate and maintain

Model	ASC9
station	1
Maximum die diameter	9"
Die thickness	0-50mm
pressure	0-7KG
Centrifugal motor	0.75KW
centrifugal speed	50-1400 rpm
Furnace	70kg (zinc alloy)
furnace	7.5KW

Other Products

Semi-automatic rubber mold spin casting machine

$2000.00 / unit
