Display technology
|
DLP chip×1,0.67"DMD
|
light source
|
New SLPL Laser Module
|
brightness
|
8500 ANSL lumens (12000 lumens market brightness)
|
Resolution
|
1920*1200
|
dynamic contrast
|
15000:1
|
color wheel
|
Fluorescent color wheel + glass color wheel 7200 rpm/min
|
color space
|
>115%REC709
|
Evenness
|
0.9
|
aspect ratio
|
16:9 / 4:3\16:10\16:6 (compatible)
|
projection lens
|
F: 1.0-1.7, 1.7X optical zoom, f=22-35mm
|
optional lens
|
LA030C:0.3:1\LA054C:0.54:1\LA065C:0.65:1\LA080C:0.8:1\LA120C:0.7-1.2:1\SLA240C:1.5-2.4:1\LA300C:1.5-3.0:1\L2043- 7211 360 degrees
|
lens shift
|
10% (horizontal electrical), 50% (vertical electrical)
|
Keystone
|
Vertical keystone correction ±30°
|
screen size
|
40 inches~400 inches
|
input interface
|
VGA computer input 1 (15 pins) × 1, DVI-I × 1, HDMI (v1.4 with audio) × 2
|
Output Interface
|
Display output (15 pins) × 1
|
control port
|
RS232 serial port (9-pin, male) input × 1, RS232 serial port (9-pin, male) output × 1, USB (Type mini B) × 1, network interface (RJ45)×1
|
Computer Compatibility
|
VGA SVGA XGA SXGA WXGA UXGA Mac
|
Video Compatibility
|
PAL, SECAM, NTSC 4.43, PAL-M, N, HDTV (480i, 480p, 575i, 575p, 720p, 1035i, 1080i and 1080P)
|
Horizontal scan frequency
|
15-100 kHz
|
Vertical brushing frequency
|
48-85 Hz
|
energy consumption
|
440W/standby <0.5W
|
power supply
|
100-240V AC
|
trumpet
|
1*10W
|
Light source life
|
Bright mode: 20000 hours; ECO mode: 25000 hours
|
Dimensions (LxWxH)
|
501*369*169mm
|
weight
|
<8KG
|
noise level
|
<37dB@33℃
|
Projection method
|
Front/Rear, Desktop/Lift
|
Exterior color
|
black and white
|
Operating temperature
|
5-35℃
|
Storage temperature
|
-10-60℃
|
menu language
|
3 languages (Chinese, English, Traditional Chinese)
|
Standard accessories
|
Power cord, remote control, VGA cable, HDMI, warranty card, qualified card
|
Qualification documents
|
3C\CECP\machine performance test report (entrusted test)
|
