China factory direct sale SBS/APP waterproof membrane production line

Supplier: Shandong Yading International Trade Co., Ltd.
Region: Shandong, China
Contact: Mr Alan Lee
Price: $100000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Supply Ability:	15 Set/Sets per Year;	Color:	painted as your requirement;
Coating:	SBS modified bitumen;	Port:	Qingdao;
Operation Mode:	Semi-automayic and automatic;	After-sales Service Provided:	Engineers available to service machinery overseas;
Place of Origin:	Shandong China (Mainland);	Brand Name:	Yading;
Type:	Auto production line;	Product name:	China factory direct sale SBS/APP waterproof membrane production line;
Capacity:	2 million, 3 million, 5 million, 10 million;	Production thickness:	2mm-5mm;
Delivery Detail:	Within 90 days after getting deposit.;	Top surface:	PE film/Sand/aluminum foil;
Application:	waterproof membrane production;	Payment Terms:	L/C,T/T,Western Union;
Packaging Detail:	waterproof membrane machine of every part is carefully packed to avoid damaging during transportation;

Product Description

China factory direct sale SBS/APP waterproof membrane production line

Bitumen Membrane (Bituminous Membrane) is widely used in industrial and civil buildings, such as, roof、 basement、toilet、bridge、park、swimming pool、tunnel for waterproof and moisture-proof. Bitumen is kind of hydrocarbon and is created naturally from crude oil. It is a useful carbon store and does not generate greenhouse gases. The membrane is therefore a sustainable way of storing carbon on the Earth's surface.
Bitumen-Mixed with rubber powder, talc powder. Meanwhile polymers are added to the bitumen such as APP (atactic polypropylene) a plastic additive that gives rigidity and tear resistance or SBS (styrene butadiene styrene) a rubber additive that gives more elastic benefits.

Product Name	SBS/APP bitumen waterproof memebrane production line
Machine Capacity	2 million square meter/year; 3 million square meter/year; 5 million square meters/year; 10 million square meters/year
Color	customized
Type	Automatic , semi-automatic
Final Products	SBS /APP bitumen waterproof membrane, self adhesive bitumen membrane
Surface material	Sand, PE, Aluminum, etc

Product Show

No.	System Device	Commodity Name
Ⅰ	Molding production line system device about asphalt shingle	1. Opening the roll equipment 2. Base fabric storage devices 3.Base fabric drying devices 4.Base fabric automatically correct equipment 5.Base cloth impregnated device 6. pressure cloth roller 7.Facing film equipment 8.suspension -type cooling device 9. supporting roller 10.embossing device 11.cooling roller 12. sand paver 13.colored sands lifting machine 14.excess sand -return device 15.automatically correct waterproofing membrane devices 16.cushion equipment 17.Bounce Conveyor 18.Automatic coiling machine 19.walking desk 20.Production line for driving device 21. inverter control cabinet
Ⅱ	Burdening system device	1. Mixing tank 2.material lifting machine 3.work platform 4.whell gear pump 5.asphalt heating tank 6.bitumen pipe 7.bitumen pump 8.dipping oil pump 9.controling cabinet for mixing system
Ⅲ	Environmental protection system device	1. Primary Spray tank 2.Secondary spray tank 3. Drain sump 4.Smoke pipeline 5.exhaust stack 6.Induced draft fan 7.Centrifugal pump 8. Controlling box
Ⅳ	Heating system device	1 main body: main body groupware, Burning engine and the attachments, blast doors, defend explosion door, Temperature oil circulatiing pump, gear filling pump, oil storage tank, expansion tank, Oil -gas segregator 2. Apparatus controlled system: electric control cabinet, double -color magnetic liquid level gage, glass plate liquid level gage, thermal resistance, joint of thermal resistance, bimetal thermometer, joint of thermometer, distant transmit pressure gauge, pressure gauge break value, heat conducting oil sampling cooler, safety valve
Ⅴ	Optional components	1.colloid mill and relaxed pipe, screw conveyor, presoak equipment, heat preservation material, water pump, cooling tower, etc
Ⅵ	Random material	1. molding production line system device about asphalt shingle: automatic coiler operating instructions; Electrical wiring diagram; frequency converter operation instruction 2. burdening system device: electrical wiring diagram, weighing instrument specification, digital thermometer user manual 3.whole machine date: equipment layout plan, equipment foundation drawing

Opening the roll equipment

Base fabric Storage Devices

Base cloth impregnated device

Send Paver

Facing Film equipment

Embossing Device

Cooling roller

Cushion Equipment

Bounce conveyor

Antomatic coiling machine

Production line control cabinet

Ingredients system

Material Lifting Machine

Controlling cabinet for mixing system

The heating systems configuration

Packing & Delivery

Our Service

Why choose US?

1. Honest supplier to the worldwide buyers

2. Factory , disrec supplier, competitive price

3. Warm and Friendly service and guide

4. Small and big orders are welcomed from the world

5. 24 hours service for you

FAQ

1. What is the loading time?

Within 90 days after getiting deposit

2. What is yout product warranty?

We guarantee the products customers receive are qualified. If there are any broken parts, please send us some detailed photos by email, and then we will send you the replacement parts according to actual conditions.

3. How about the trade term?

EXW, FOB, CNF, CIF are all ok.

4. How about the payment method?

30% T/T deposit +65% T/T before loading +5% T/T balance after testing machine

5. What is the Loading port?

Qingdao, China
