VQ9H specifications |
model |
wxya |
application |
V380 Professional Edition |
pixel |
720P (1280*720P) |
sensor |
SC1245+YB32 |
lens |
Focal length 2.6mm aperture F2.4 |
Resolution: |
1280*720 |
video frame rate |
(day, night vision, HD, normal definition): 15fps |
code flow: |
H.264 |
Angle of view: |
81 degrees |
Night vision distance: |
3~5 meters |
Infrared Compensation: |
8 F5 infrared LEDs (940nm) |
WiFi fixed frequency |
2.4G |
Loop recording function |
Yes |
Battery Type |
LiPo 3.7V |
battery capacity |
500mA |
day mode recording time |
about 2 hours at 25°C |
Daytime video power consumption |
About 230mah 3.7V |
Night vision mode recording time |
About 1.3 hours at 25°C |
Night Vision Video Power Consumption |
About 370mah 3.7V |
record distance |
3~5 meters |
speaker |
Do not |
WiFi connection distance |
≥30m (open without interference and obstruction) |
point-to-point distance |
≥30m (open without interference and obstruction) |
video format |
video file |
video memory per minute |
4-5MB |
Metric type/number. |
3 LEDs (red, yellow and blue) |
USB |
Micro USB |
Charging requirements (rated constant voltage current) |
5V,1A |
Supported systems and players |
Windows, IOS, Android storm video |
memory card capacity |
Maximum support 128G (requires FAT32 format) |
Product Size |
Diameter 82mm * height 119mm |
Package dimensions |
Length 9.6*width 9.8*height 4cm |
temperature |
5~40℃ |
humidity |
Relative humidity 45%~85% |
This product is suitable for indoor environment only. Do not block the cooling holes |
