Weight (kg): | 750 kg | place of origin; place of origin: | Jiangsu, China |
Marketing Type: | New Products 2021 | Core component warranty: | 1 year |
Supply capacity: | 800 sets per month | port: | Shanghai |
Package preview: | Applicable industries: | Hotels, clothing stores, building supplies stores, machinery repair shops, manufacturing plants, food and beverage factories, farms, restaurants, home use, retail, food stores, printing shops, construction, energy and mining, food and beverage stores, advertising agencies | |
Packaging Details: | All kinds of electric stacker wood packaging, HS code: 84271090 | Showroom location: | not any |
Dimensions (L*W*H): | 2600*1000*2450mm | Video shipment inspection: | if |
Mechanical test report: | if | Core components: | engine |
State of health: | new | Warranty: | 1 year |
payment terms: | wire transfer | product name: | Electric Stacker |
brand: | pangolin |
product model | unit | CQD-S forward moving electric stacker | ||||
steering pattern | permanent | |||||
specified load | Kilogram | 1000/1500/2000 | ||||
load center | mm | 500 | ||||
Weight (with battery) | Kilogram | 1600/1650/1750/1800/1850 | ||||
Front and rear wheel size | mm | φ150*85/250*80 | ||||
tire | polyurethane wheel | |||||
Number of wheels (front/rear x=drive wheels) | 1x+2/4 | |||||
wheelbase | mm | 1350 | ||||
Overall height (forks in lowest position) | mm | 2100/1650/1850/2150/2450/2650 | ||||
Lifting height | mm | 1600/2000/2500/3000/3500/4000 | ||||
Fork height from the ground (minimum) | mm | 50 | ||||
total length | mm | 3000 | ||||
Advance distance | mm | 500 | ||||
overall width | mm | 1050 | ||||
Pallet Fork Dimensions (Sheet Metal) | mm | 40*10*1070 | ||||
Fork outer width | mm | 700 | ||||
Aisle width, with 1000*1200 pallets | wind speed(mm) | 3500 | ||||
Aisle width, with 800*1200 pallets | wind speed(mm) | 3000 | ||||
Turning radius | mm | 2500 | ||||
brake method | Electromagnetic brake | |||||
Lifting speed, loaded/unloaded | km/h | 10/12 | ||||
Drive motor power | kilowatt | 1.5 | ||||
Lifting motor power | kilowatt | 2.2 | ||||
Lifting speed (full load/no load) | mm/s | 130/100 | ||||
Descent speed (full load/no load) | mm/s | 100/80 | ||||
Battery voltage/capacity | voltage/ah | 24/210 | ||||
noise | decibel (A) | ≤70 | ||||
