Rim manufacturer tractor steel rim W12x30 agricultural machinery parts tractor rim

Click here to contact

Product details

Warranty:	1 year	Package preview:
After warranty service:	Video Technical Support	width:	12 inches
product name:	tractor wheel	quality:	Top 10 in China
brand:	magnificent	delivery time:	7-15 days
Serve:	24 hours	finishing:	bright
payment terms:	L/C, Western Union, T/T	Packaging Details:	Standard export packaging
application:	DOT ECE REACH CCC GCC INMETRO NOM	size:	width 12x30
place of origin; place of origin:	Shandong China	season:	all
brand:	magnificent	Supply capacity:	1,000,000 pieces per year
Polycarbonate:	203.2mm	Material:	Natural rubber and steel in Malaysia
port:	Qingdao	Alien:	15mm, 18mm, 30mm, 100mm

Product Description

wheel size (tire size)	Convention on Biological Diversity Center hole	PCD distribution circle	bolt hole number of screw holes	Bolt connection hole diameter	connection typeconnection method	offset
width 12x30	152.4	203.2	8	twenty one	Bolted	25.4/20/18
		162.4	203.2	8	twenty one	Bolted	65
		220	275	8	19	welding	76/60
		220	280	8	twenty three	Bolted	45
		281	335	10	twenty one	bracket connection	35
		290.5	330	8	17	bracket connection	50

Recommended Products

Product parameters

wheel size Wheel model	Bolt hole number Number of screw holes	Bolt hole diameter screw hole line	polysilicon distribution circle	Convention on Biological Diversity Center hole	offset Offset	Equipped with tires tire model
4.00Ex15	5	15	140	96	25	5.00-15
4.00Ex16	4	17	127	92.2	10	5.00-16
5.5Fx16	6	19	152	117.7	0	7.50-16
5.5Fx20	6	19	180	141	10	7.50-20
W7x20	6	17	161	102	65	8.3-20
W7x24	6	17	161	100	15	8.3-24
width 8x24	6	20	205	161	68.7	9.5-24
width 10x24	6	18.5	165	120	76	11.2-24
width 12x24	8	17	330	290.5	26	13.5-24
width 13x24	8	18.5	203.2	152.6	26	14.9-24
W13x26	8	17	330	290.5	26	14.9-26
W10x28	8	17	203.2	151.3	4	11.2-28
W11x28	8	17	203.2	151.3	4	12.4-28
W10x32	8	17	203.2	151	4	11.2-32
W11x38	8	twenty one	203.2	152.4	16	12.4-38
W15x38	8	19	203.2	150.1	20	16.9-38
W15x42	8	twenty four	275	221	106	16.9-42
W16x42	8	17.5	203.2	150.1	92.5	18.4-42 years old
W8x48	8	twenty four	250	199	18	9.5-48
W13x48	10	26	335	282	110	14.9-48
W10x54	8	twenty four	250	199	193	11.2-54
W11x54	10	twenty four	335	282	221.5	12.4-54
DW15x34	8	19	203.2	152.6	18	16.9-34
		8	21.4	203.2	152.6		75
		10	twenty four	335	281.5		0
DW12x38	8	20.5	203.2	152.4	69.5	13.6-38 years old
DW12x38		8	20.5	203.2	152.4	13.6-38 years old	213
DW16x42	10	twenty four	335	281.5	38	18.4-42 years old
		10	twenty four	335	281.5		14
		10	twenty four	335	281.5		177
