port: | Shenzhen | model: | you think |
Guidance Type: | Permeance | Minimum turning radius: | 600mm |
place of origin; place of origin: | Angola | Direction of movement: | two-way |
application: | Smart Warehousing | Certification: | CE certification |
payment terms: | Western Union, T/T, MoneyGram, PayPal | use: | shopping center |
capacity: | 50-300kg | MOQ: | 1 |
brand: | you think | Running speed: | 0-40m/min |
Packaging Details: | in wooden box | TOLL: | car |
Supply capacity: | 300 pieces per month | product name: | Lurking and Lifting AGV |
Package preview: |
AGV charging station/AGV five-connection/smart handling AGV trolley
Navigation: Magnetic Stripe
Speed: 0-40m/min
Turning radius: 600mm
Orientation: double
Loading method: back to shelf
Load weight: 50-300Kgs
Communication: WIFI (Serial Wi-Fi)
Original rotation: support
Basic size: 900*500*250mm (top plate 380mm)
Custom: support
Others: Butt joint accuracy 5mm, warehouse material butt joint, jacking stroke 40mm
feature:
1. Applied to automatic three-dimensional warehouse, production line pallet/pallet automatic handling, etc.
2. Combined with pager and dispatching system to realize automatic transfer of on-site production process.
3. Highlight function: realize automatic connection of loading, unloading and transportation, and minimize manual labor.
thing |
scope |
Comment |
navigation |
Magnetic |
American chips, stable quality |
motor |
Brushless DC Motor |
servo motor |
controller |
Professional AGV Controller |
Embedded motherboard, high-speed switching |
drive mode |
dual drive |
flexible steering |
loading method |
Carrying/tail dragging/lurking |
Both loading modes can be used together |
specified load |
50KG-4T |
|
Automatic running direction |
one direction/two directions |
Manually forward, backward, left, right. |
speed |
0.2m/s~1.0m/s |
go straight |
Minimum turning radius |
0.5 miles |
Arc turning |
size |
800*500*250mm, 650*450*370mm |
other sizes available |
Security type |
Radar + infrared + safety belt |
|
Safety protection distance |
1.5 miles slow -> 0.5 miles stopped -> collision protection |
Can be adjusted according to different AGVs |
communicate |
wireless online |
Remote can be used within 1000m |
scheduling system |
support |
call, traffic, dispatch |
