Fast delivery low cost pcb manufacturing POE OEM manufacturing pcb board rigid flex high frequency pcb

Click here to contact
Product details
MOQ:1type:High frequency circuit board
Minute line spacing:3000000Origin:Guangdong, China
Substrate:Shengyi, DuPont, PIServe:24 hours technical service
Packaging Details:PCB PCBA Manufacturing,Flexible PCB Electronic Circuit Board PCB Assembly PCB: Vacuum Packing with Carton Box PCBA: ESD Packing with Carton BoxBoard Dimensions:Custom PCB Dimensions
Supply capacity:150,000 square meters per yearKey words:High frequency circuit board
Minute Hole Size:0.1-6.5mmProduct quotation:within 2 hours
Sample delivery:within 24 hoursPackage preview:
port:Shenzhen/GuangzhouPrinted Circuit Board Standards:IPC-A-600
model:High frequency circuit boardSolder Mask:Green solder mask/black PI/yellow PI
Copper thickness:0.5-2ozpayment terms:L/C, Western Union, D/P, D/A, T/T, MoneyGram, Alipay
Surface treatment:ENIG,HASL,OSP,ENEPIG,Flash Goldbrand:Summit Electronics Co., Ltd.
Minute line width:3000000Plate thickness:0.1-0.5mm
Maximum number of layers:8Llegend:white, black, red, yellow



Fast delivery low cost pcb manufacturing POE OEM manufacturing pcb board rigid flex high frequency pcb

product information



thing boring flexible rigid-flexible
Maximum number of layers 60L 8L 36L
Inner layer minimum trace/space 3/3 million 3/3 million 3/3 million
Minimum trace/space on outer layers 3/3 million 3.5/4 million 3.5/4 million
Inner Layer Maximum Copper 6 oz 2 oz 6 oz
outer layer copper 6 oz 2 oz 3 oz
Minimal Mechanical Drilling 0.15mm 0.1mm 0.15mm
Minimal Laser Drilling 0.1mm 0.1mm itemRIGIDFLEXRIGID-FLEX 0.1mm
Aspect Ratio (Mechanical Drilling) 20:1 10:1 12:1
Aspect Ratio (Laser Drilled) 1:1 / 1:1
Press hole tolerance ±0.05mm ±0.05mm ±0.05mm
PTH tolerance ±0.075mm ±0.075mm ±0.075mm
NPTH tolerance ±0.05mm ±0.05mm ±0.05mm
countersunk tolerance ±0.15mm ±0.15mm ±0.15mm
plate thickness 0.4-8mm 0.1-0.5mm 0.4-3mm
Plate thickness tolerance (<1.0mm) ±0.1mm ±0.05mm ±0.1mm
Plate thickness tolerance (≥1.0mm) ±10% / ±10%
Impedance tolerance Single-ended: ±5Ω (≤50Ω), ±7% (>50Ω) Single-ended: ±5Ω (≤50Ω), ±10% (>50Ω) Single-ended: ±5Ω (≤50Ω), ±10% (>50Ω)
Differential: ±5Ω (≤50Ω), ±7% (>50Ω) Differential: ±5Ω (≤50Ω), ±10% (>50Ω) Differential: ±5Ω (≤50Ω), ±10% (>50Ω)
Minimum board size 10*10mm 5*10mm 10*10mm
board size 22.5*30 inches 9*14 inches 22.5*30 inches
Profile Tolerance ±0.1mm ±0.05mm ±0.1mm
Minimum BGA 7 million 7 million 7 million
Minimum SMT 7*10 million 7*10 million 7*10 million
surface treatment ENIG, Gold Finger, Immersion Silver, Immersion Tin, HASL(LF), OSP, ENEPIG, Flash Gold; Hard Gold Plating ENIG, Gold Finger, Immersion Silver, Immersion Tin, HASL(LF), OSP, ENEPIG, Flash Gold; Hard Gold Plating ENIG, Gold Finger, Immersion Silver, Immersion Tin, HASL(LF), OSP, ENEPIG, Flash Gold; Hard Gold Plating
Solder mask Green, black, blue, red, matte green Green solder mask/black PI/yellow PI Green, black, blue, red, matte green
Minimum Solder Mask Clearance 1.5 million 3000000 1.5 million
Minimum Solder Dam 3000000 800w 3000000
legend white, black, red, yellow white, black, red, yellow white, black, red, yellow
Minimum legend width/height 4/23 million 4/23 million 4/23 million
Strain Fillet Width / 1.5±0.5mm 1.5±0.5mm
bow and twist 0.30% / 0.05%
