Coverage: | 500 square meters | verify: | cerium |
type: | signal booster | Standing wave: | ≤1.5dB |
power supply: | DC12V/2A | model: | SS91-GDW, SS91-GDW |
Output Power: | 20dBm | port: | Shenzhen |
product name: | mobile repeater | Packaging Details: | Carton packing, 20pcs/box |
payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram | Origin: | Guangdong, China |
Package preview: | network: | 4g, GSM, 3G, FDD | |
Connector: | NK | frequency: | 900/1800/2100Mlz |
Supply capacity: | 20000 pieces per month | get: | 60~70dB |
brand: | signal smith |
specifications | ||||||
model | SS91-GDW | |||||
parameter data | uplink | downlink | ||||
Frequency Range | GSM | 890~915MHz | 935~960MHz | |||
distributed control system | 1710~1785 MHz | 1805~1880MHz | ||||
WCDMA | 1920~1980MHz | 2110~2170MHz | ||||
Output Power | 20±2dBm | 20±2dBm | ||||
get | 65±2dB | 70±2dB | ||||
in-band ripple | ≤3dB | |||||
Intermodulation products | 9KHz~1GHz | ≤ -36 dB | ||||
1GHz~12.75GHz | ≤ -30 dB | |||||
spurious emission | 9KHz~1GHz | ≤ -36 dB | ||||
1GHz~12.75GHz | ≤ -30 dB | |||||
Noise Figure | ≤ 6 dB | |||||
VSWR | ≤2 | |||||
power supply | AC: 100~240V, 50/ 60Hz; DC: 12V 2A | |||||
power consumption | < 24W | |||||
impedance | 50 ohms | |||||
Mechanical Specifications | ||||||
RF connector | N-Female | |||||
Dimensions (LxWxH) | 235*182*21(mm) | |||||
weight | ≤ 1.2Kg | |||||
Operating temperature | -10°C ~ 55°C |
