CE certified 32 inch 1366*768 non-touch screen TFT LCD module HV320WHB-F70

Supplier: Guangzhou Zhangao Electronics Co., Ltd.
Region: Guangdong, China
Contact: Mr bing Hu
Price: $60.00 / 1 - 16 pieces
$55.00 / 17 - 271 pieces
$48.00 / >=272 pieces
Min. Order: 1 piece

Click here to contact

Product details

Packaging Details:	carton	Brightness (cd/m²):	0
payment terms:	Western Union, T/T	Supply capacity:	3200 pieces per quarter
Display size:	32.0"	Display size:	697.685 * 392.256 mm (height * vertical)
type:	thin film transistor	solve:	1366(RGB)*768【WXGA】49PPI
screen size:	32.0"	Surface treatment:	Matte (1% haze), hard coat (3H)
Package preview:		Screen type:	Liquid crystal glass, a-Si TFT-LCD
Origin:	Guangdong, China	Pixel configuration:	RGB vertical bar
Physical Dimensions:	7154111.32 mm (HVD)	Best angle:	full view
Supplier type:	monitor	Model Name:	HV320WHB-F70

Product Description

Model Name	HV320WHB-F70
screen size	32.0"
screen type	Liquid crystal glass, a-Si TFT-LCD
solve	1366(RGB)*768【WXGA】49PPI
pixel configuration	RGB vertical bar
display size	697.685 * 392.256 mm (height * vertical)
physical size	7154111.32 mm (HVD)
surface treatment	Matte (1% haze), hard coat (3H)
Brightness(cd/m²)	0
Compared	1200 : 1 (Typical) [Transmission]
best angle	full view
optical mode	ADS, Normally Black, Transmissive
Viewing angle	89/89/89/89 (typical value) (CR≥10)
responding speed	8 (typical) (G to G) ms
glass thickness	0.50+0.50mm
Transmittance	6.5% (Typ.) (with polarizer)
number of colors	16.7 million, 72% NTSC
Backlight type	no backlight
screen weight	852 g (typical)
refresh rate	60 Hz
touch function	don't touch
signal system	Mini LVDS , Terminal, 60 pins
maximum rating	Storage temperature: -20～60℃ Working temperature: 0～50℃
