Video shipment inspection: | if | Origin: | Henan, China |
expiration of pay: | T/T, used Zoomlion concrete pump truck | Applicable industries: | Mechanical repair shops, home use, construction, energy and mining |
productivity: | 15 cubic meters / hour | Supply capacity: | 10 concrete truck pumps per month |
Packaging Details: | Meet export packaging requirements. 1. Concrete mixing pumps, trailer concrete pumps and other small container machinery. Spare parts in wooden case or steel case. 2. Concrete pump trucks, concrete mixer trucks, concrete pump trucks and other equipment are transported by ro-ro ships, bulk carriers or flat racks. | payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram |
maximum. Vertical conveying distance: | 120M | port: | Tianjin/Lianyungang/Qingdao/Shanghai |
Key words: | concrete mixer truck | transportation: | Shipping, second-hand Zoomlion concrete pump truck |
strength: | 12 cubic meters / hour | weight: | 44000 kg |
MOQ: | 1 set, Zoomlion second-hand concrete pump truck | type: | concrete mixer truck |
maximum. Horizontal conveying distance: | 42M, used Zoomlion concrete pump truck, 50M | After warranty service: | Video technical support, second-hand Zoomlion concrete pump truck |
product name: | Used Concrete Pumps For Sale In Good Condition | Power type: | Diesel engine, second-hand Zoomlion concrete pump truck, diesel engine |
Package preview: | Mechanical test report: | if | |
Core components: | Pressure vessels, motors, bearings, gears, pumps, gearboxes, engines | Year: | 2016 |
Unique selling point: | High operating efficiency, second-hand Zoomlion concrete pump truck | model: | ZLIN5320THB 42M |
Showroom location: | not any | operating hours: | 2001-4000 |
feature:
1.high configuration: Adopt the core components of international high-end brands and becomeLong-term strategic partnerCooperate with German Spall, Rexroth, Harvey, HBC, Italian Wolff, NEM, American Eaton and other companies;
2.Stable performance, low failure rate: Through 3D modeling and finite element analysis, the structure is more reasonable and the performance of the whole machine is more stable; the failure rate has been very low and then exceeded20 years market test;
3.High construction efficiency and wide construction scope: Equipped with high and low pressure automatic switching function, pumping isSelf-adaptive, energy-saving and efficient;
4.Powerful Human-Computer Interaction, intelligent control is easy to operate,simpleAnd clear Troubleshooting.
If you need more products or information, please send an inquiry
Boom Outrigger Parameters | Boom Vertical Height | 43.7m | ||
Boom horizontal length | 39.7m | |||
boom vertical depth | 26.2m | |||
Boom folded form | 5RZ | |||
first arm | length | 9500mm | ||
corner | 90o | |||
second arm | length | 7100mm | ||
corner | 180 degree | |||
third arm | length | 6700mm | ||
corner | 180 degree | |||
fourth arm | length | 8000mm | ||
corner | 229o | |||
fifth arm | length | 8400mm | ||
corner | 212o | |||
end delivery hose | length | 3 meters |
If you need more products or information, please send an inquiry
to pump water system parameter |
Blender model | JS750 |
Concrete Theoretical Displacement | >=25 cubic meters/hour | |
Dispensing valve form | S valve | |
Delivery cylinder inner diameter/stroke | 230/1600mm | |
Main oil pump displacement | 190ml/rev | |
Delivery pipe inner diameter | 125mm | |
Maximum Aggregate Size | 40mm | |
concrete slump | 160-220mm | |
System oil pressure | 31.5MPa | |
Hydraulic oil tank volume | 500L | |
hydraulic system type | Open | |
High and low voltage switching | auto switch | |
Hydraulic oil cooling method | air cooled | |
Concrete pipe cleaning method | wash | |
Lubrication method | centralized lubrication |
