maximum. Working radius: | 7950mm | Warranty: | 1 year |
Mechanical test report: | if | maximum. Operating pressure: | 34.3MPa |
maximum. Digging depth: | 15200mm | brand: | Tessim |
Origin: | Jiangsu, China | payment terms: | L/C, Western Union, T/T, MoneyGram |
maximum. Lifting height: | 2870mm | Packaging Details: | One is bare-packed, Ro-Ro ship sea transportation as a whole (L*W*H=9150*2600*3250mm); the other is the main engine in a flat rack; the kelly and bucket are also bare-packed, and there are four A wooden box, which contains the mast, power head, follower frame and maintenance spare parts. |
Applicable excavator (ton): | 3-5,6-8 | product name: | Hydraulic soil drill |
Core components: | Pump | weight: | 3.6 tons, 116 |
port: | Shanghai, Tianjin, Qingdao | Video shipment inspection: | if |
Minute operating radius: | 3980mm | Showroom location: | Turkey, United Kingdom, United States, Germany, Vietnam, Philippines, Brazil, Indonesia, Pakistan, India, Mexico, Thailand, Morocco, Kenya, Argentina, United Arab Emirates, Colombia, Algeria, Sri Lanka, South Africa, Kazakhstan, Ukraine, Kyrgyzstan, Tajikistan ,Malaysia |
Health status: | new | maximum. Operating height: | 9475mm |
Maximum vertical digging radius: | 6430mm | Marketing Type: | New Products 2020 |
model: | KA series | Bucket capacity: | 0.3 cubic meters |
Applicable industries: | Farms, Hotels, Retail, Construction | Supply capacity: | 200 sets per month |
Auger Specifications | ||||||||||||||
type | unit | KA2500 | KA3000 | KA3500 | KA4000 | KA6000 | KA8000 | |||||||
Applicable excavator | Ton | 1.5-3 tons | 2-4 tons | 2.5-4.5 tons | 3-5T | 4.5-6 tons | 5-7T | |||||||
torque | cow rice | 790-2593 | 1094-3195 | 1374-3578 | 1710-4117 | 2570-6917 | 3163-8786 | |||||||
pressure | bar | 70-240 | 80-240 | 80-240 | 80-240 | 80-240 | 80-240 | |||||||
flow | Rotating speed | 25-65 years old | 25-70 | 40-80 | 50-92 | 40-89 | 48-110 | |||||||
Rotating speed | Rotating speed | 36-88 | 30-82 | 35-75 | 35-68 | 20-46 | 20-45 years old | |||||||
Output shaft | mm | 65 rounds | 65 rounds | 65 rounds | 65 rounds | 75 square meters | 75 square meters | |||||||
weight | Kilogram | 95 | 100 | 105 | 110 | 105 | 110 | |||||||
Max Helix Diameter Clay/Shale | mm | 300 | 300 | 350 | 350 | 500 | 600 | |||||||
Largest Auger Diameter Earth | mm | 350 | 400 | 450 | 500 | 600 | 800 |
Auger Specifications | ||||||||||||||
type | unit | KA9000 | KA15000 | KA20000 | KA25000 | KA30000 | KA59000 | |||||||
Applicable excavator | Ton | 6-8 tons | 10-15 tons | 12-17 tons | 15-22 tons | 17-25 tons | 20-35 tons | |||||||
torque | cow rice | 3854-9961 | 5307-15967 | 6715-20998 | 8314-25768 | 15669-30393 | 27198-59403 | |||||||
pressure | bar | 80-240 | 80-260 | 80-260 | 80-260 | 80-260 | 160-350 | |||||||
flow | Rotating speed | 70-150 | 80-170 | 80-170 | 80-170 | 80-170 | 100-250 | |||||||
Rotating speed | Rotating speed | 23-48 | 23-48 | 15-32 | 12-26 | 12-21 | 10-22 | |||||||
Output shaft | mm | 75 square meters | 75 square meters | 75 square meters | 75 square meters | 75 square meters | 110 square meters | |||||||
weight | Kilogram | 115 | 192 | 200 | 288 | 298 | 721 | |||||||
Max Helix Diameter Clay/Shale | mm | 800 | 900 | 1000 | 1100 | 1200 | 1500 | |||||||
Largest Auger Diameter Earth | mm | 1000 | 1200 | 1400 | 1500 | 1600 | 2000 |
