Aluminum Chevies Complete Cylinder Heads For GM Chevy BBC Big Block 454 320cc 115cc High Performance

  • Supplier: Ningbo Kinghan Auto Parts Co., Ltd.
  • Region: Zhejiang, China
  • Contact: Mr Henry W
  • Price: $135.00 / 1 - 4 pieces
    $130.00 / 5 - 19 pieces
    $125.00 / 20 - 49 pieces
    $115.00 / >=50 pieces
  • Min. Order: 1 piece
Product details
brand:Japanese and Koreanreference number. :HL0098
Original serial number:FF281.1003Warranty:18 months
car model:Chevrolet 454Tapa motor:Chevrolet 454
payment terms:L/C, Western Union, T/Tsize:55.5*24.5*17.5CM
port:NingboPackaging Details:One pc cylinder head in one carton, 50 cylinder heads in one pallet
Origin:ChinaGlowica Cylinder:FF281.1003
Supply capacity:1000 pieces per monthCylinder Hoved:GM Chevrolet BBC Big Block 454
Package preview:Engine code:Chevrolet 454
Product Description
Aluminum Chevies Complete Cylinder Head for GM Chevy BBC Big Block 454 320cc 115cc High Performa

suitable for car
Part Number: FF281.1003 Part Type: Cylinder Head Cylinder Head Style: Assembled Cylinder Head Material: Aluminum Cylinder Head Finish: Natural Combustion Chamber Volume (cc): 115 cc CNC Machined Combustion Chamber: No Inlet Port Volume (cc) : 320 cc Exhaust Runner Volume (cc): N/A CNC Machined Inlet Runner: No CNC Machined Exhaust Runner: None Inlet Shape: Rectangular Inlet Location: Standard Exhaust Shape: D Port Exhaust Port Location: Standard Spark Plug Style: OEM Comparison. Valve Operation: None Inlet Valves Included: Yes Intake Valve Diameter (inches): 2.250 inches Exhaust Valves Included: Yes Exhaust Valve Diameter (inches): 1.880 Including Valve Springs: Yes Maximum Valve Lift (inches): 0.650 Inches Outer Spring Diameter (Inches): 1.550" Damper Spring Included: Yes Number of Springs Per Valve: Included Dual Retainer: Yes Retainer Material: Chrome Steel Included Lock: Yes Lock Style: 10 Degree Stem Seal Included: Yes Stem Seal Style: Forced Stop Included Rocker Stud: Not Included Rocker: Not Included Rocker Nut: Not Included Guide Plate: No Bonnet Mounting Method: Peripheral Bolt Attachment Bolt Hole Drilling: Yes 24 degrees. Exhaust valve angle: 15 degrees. Valve Guide Included: Yes Valve Guide Material: Bronze Seat Machining: Yes Seat Machine Style: 3 Angle Seat Material: Ductile Iron Drilled Steam Hole: No Refueling Method: Via Push Rod

brand
application
engine model
displacement
original equipment manufacturer
General Motors
Chevrolet BBC Big Block 454 320cc
Chevrolet 454
5.7L
FF281.1003
