controller
|
toyota brand
|
engine
|
5KW AC motor
|
Battery
|
72V120AH lithium battery
|
|
Carrying capacity
|
4 (2+2)
|
range(load)*
|
70-80 kilometers
|
Maximum speed
|
32-40km/h
|
minute turning radius
|
3 meters
|
maximum. Gradeability
|
20%
|
maximum. loading weight
|
320 kg
|
net weight
|
510 kg
|
Dimensions
|
2950X1340X1990mm
|
body and frame
|
Frame (chassis)
|
Welded steel frame, pickling, phosphating, electrophoresis anti-rust treatment
|
body and roof
|
PP plastic front and rear; FRP roof
|
windshield
|
Organic plastic windshield, one-piece
|
roof bracket
|
carbon steel, powder coated
|
backrest and seat
|
Reborn Sponge, Faux Leather + Plastic Armrests
|
ground
|
Galvanized steel and non-slip rubber floor mats
|
Dashboard
|
Black Plastic with 4 Cup Holders, 2 Glove Organizers, Forward/Reverse Switch, Battery Level Indicator, Ignition Key
|
side trim
|
aluminum alloy
|
side mirror
|
2 pcs, collapsible
|
Electrical System
|
Lighting system and horn
|
Full LED lights, 2 headlights, 2 front turn signals, 2 tail lights (each combining 1 brake light and 1 turn signal), with 20A reducer (conversion from 72V to 12V), electric horn.
|
spare buzzer
|
12V
|
charger
|
Smart charger, input 110V-240V~50Hz-60Hz, output 72V, 20A
|
Steering, Braking, Transmission and Suspension
|
steering system
|
Single stage rack and pinion steering system, automatic rocker arm compensation function
|
Brake system
|
Rear wheel mechanical brake, pedal parking brake
|
accelerator
|
CVT
|
driving mode
|
Two-stage deceleration of the rear axle, directly driven by the motor
|
rear axle
|
One-piece, gear ratio 12.49:1
|
suspension system
|
Front and rear leaf spring + oil cylinder hydraulic shock absorber
|
Wheels and Tires
|
10x8 aluminum rims and 22*11-10 tires
|
