port: | Guangzhou | Package preview: | |
Origin: | Guangdong, China | payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram |
printer: | Elective | color: | Black |
Name: | Portable Refractometer | Packaging Details: | Smallest Handheld Automatic Refractometer HA01PLUS Refractometer Price Standard Package |
Astigmatism axis range: | 1°~180 | Warranty: | 12 months, 12 months |
product name: | Automatic refractometer | Cylinder range: | -5.OD ~ +5.OD |
Customization support: | OEM production | connect: | usb, wireless network. |
Supply capacity: | 1000 sets per year | Key words: | Refractometer |
brand: | Mai Xinglong | Sphere range: | -10.OD ~+1O.OD |
model: | MSLHA01PLUS |
Handheld Automatic Refractometer HA01 Refractometer with Keratometer
Handheld Automatic Refractometer Specifications
Sphere range -10.OD ~+1O.OD, step size 0.25D
Cylinder range -5.OD ~ +5.OD. Step 0.25D
Astigmatism axis range 1°~180°, 1°
Data collection time s/eye
iris imaging is
Connect USB, Wi-Fi;
Easily transfer data to PC or printer
Print to printer (optional)
Dimensions203mm x 11omm x 5Omm
Specifications are subject to change without notice.
Operating Mode: Bino/Mono
Optometry: Automatic
DS: Range: -7.50D~+7.50D
Resolution: 0.25D/0.01D
Accuracy: ±0.50D
DC: Range: 0.00D~3.00D
Resolution: 0.25D/0.01D
Accuracy: ±0.50D
Axis: Range: 1°~180°
Resolution: 1°
Accuracy: ±5°
Pupil size: Range: 4.0 mm~9.0 mm
Resolution: 0.1mm
Accuracy: ±0.1 mm
Pupil distance: Range: 35 mm~80 mm
Resolution: 1mm
Accuracy: ±1mm
Gaze: 0°~ 20°
Measuring distance: 1 m ± 5 cm
Each measurement time: ~1s
Fixed target: flashing light, pleasant sound
Data interface: Wi-Fi, USB
Printer interface: USB
Battery: Rechargeable lithium battery, lasts 6 hours, replaceable
Size: 180mm×130mm×110mm
Display: 5 inch touch screen
Weight: 0.8Kg
Optional accessories: camera tripod, printer, etc.
