Tire: | 10.0/75-15.3 16pr; | After-sales Service Provided: | Free spare parts,Video technical support,Online support; |
Certification: | ISO9001 CE; | Supply Ability: | 450 Set/Sets per Month; |
After-sales Service Provided: | Engineers available to service machinery overseas; | Brand Name: | zeyi; |
Features: | Hydraulic Dump; | Weight: | 680 kg; |
Warranty: | 1 Year; | Payment Terms: | L/C,T/T,Western Union; |
Port: | Qingdao port; | Deadweight(kg): | 1160 KG; |
Overall dimension(mm): | 4900*1820*1810; | Packaging Detail: | iron plate; |
Brake form: | air brake; | Place of Origin: | Shandong China (Mainland); |
Model: | 7CX-D3+3; | Rated weight(kg): | 3000 x2 KG; |
Carriage dimension(mm): | 3400*1700*(460+460); | Condition: | New; |
Application: | Transportation; | Unload form: | back tipping(three way tipping can select ); |
Model | Carriage size(mm | Overall dimension(mm) | Upload | Weight | Tyre | Unload way | Matched power | Brake | Quantity /40GP |
7CX-D3+3 | 3400*1700*(460+460) | 4900*1820*1810 | 3000 | 1160 | 10.0/75-15.3 16pr | back tipping | air brake and hand brake | 24-30 | 16 |
7CX-D4+4 | 3400*2000*(460+460) | 4900*1820*1860 | 4000 | 1325 | 11.5/80-16.3 16pr | three way tipping | air brake and hand brake | 24-30 | 16 |
7CX-D5+5 | 3700*1900*(460+460) | 5020*1990*1855 | 5000 | 1350 | 400/60-15.5 14pr | back tipping | air brake and hand brake | 40-50 | 16 |
7CX-D5+5 | 3700*1900*(460+460) | 5020*1990*1855 | 5000 | 1420 | 400/60-15.5 14pr | three way tipping | air brake and hand brake | 40-50 | 16 |
7CX-D6+6 | 4100*2100*(550+550) | 5830*2200*2265 | 5000 | 2165 | 11.5/80-15.3 10pr | three way tipping | Air brake | 50-60 | 16 |
7CX-D7+7 | 4100*2100*(460+460) | 5830*2200*2050 | 7000 | 2100 | 10.0/75-15.3 16pr | three way tipping | Air brake | 50-60 | 10 |
7CX-D8+8 | 4100*2100*(550+550) | 5830*2200*2260 | 8000 | 2315 | 11.5/80-15.3 16PR/4 | Hydraulic dump (left and right) | Air brake | 60-80 | 10 |
